59
Appendix A
AAAAA
Technical pecifications
Technical pecifications A
Transceiver unit SAILOR 6222 VHF DSC
Item Specification
Weight SAILOR 6222 VHF
DSC
< 1.50 kg (3.3 lbs) approximately
Box weight
SAILOR 6222 VHF DSC
3.8 kg (8.4 lbs) approximately, including
SAILOR 6201 Handset with cradle and wall
mount cradle, SAILOR 6204 Control Speaker
Microphone and Installation and user manual
in box.
Dimensions Height: Outer dimension 107 mm, hole height
for flush mount 89 mm
Width: Outer dimension 241 mm, hole width
for flush mount 227 mm
Depth: Outer dimension from front of knobs
132 mm, depth for flush mount 94 mm
Operating temperature -25°C to 55°C (5°F to 131°F)
Storage temperature -30°C to 80°C (-22°F to 176°F)
Power supply 12 VDC Nominal (10,8– 15,6 VDC)
Current consumption Max. 7 A
Current consumption at
12 VDC (no accessories
connected)
RX: 0.5 A
TX: 5 A
Current consumption at
12 VDC (all accessories
connected)
RX: 0.7 A
TX: 7 A
