Appendix A: Technical pecifications
62 NMEA data rates and formats
NMEA data rates and formats
SAILOR 6090 Power Converter 24—12 V
Modulation 1700 Hz ± 400 Hz. 1200 baud
Frequency error Below ± 1 Hz
Residual modulation Below —26 dB
Item Value
61162-1 4800,8,n,1
61162-2 38400,8,n,1
Item Description
Item Description
Weight 300 g
Dimensions Height: 33 mm
Width: 190 mm
Depth: 85 mm
Operating temperature -25°C to 55°C (5°F to 131°F)
Storage temperature -30°C to 80°C (-22°F to 176°F)
Input voltage 21—32 VDC
Output voltage 12.5 VDC
Output current (max.) 8 A
