4
Part 2 Specifications
Gas Connection
CR6 Model
Gas supply connection point is located at the rear
of the appliance, approximately 130 mm from the
right hand side, 45 mm from the rear and 655 mm
from the floor and is reached from beneath the
appliance. (Refer to the ‘Dimensions’ below).
For all Appliance Options, gas connection is
3
/
4
” BSP
male.
Dimensions
CR6 Model
CR9A Model CR9B Model
CR9C Model CR9D Model
CR9 Model
Gas supply connection point is located at the rear
of the appliance, approximately 130 mm from the
right hand side, 20 mm from the rear and 655 mm
from the floor and is reached from beneath the
appliance. (Refer to the ‘Dimensions’ below).
For all Appliance Options, gas connection is
3
/
4
” BSP
male.
CR9 Model
CR6B Model CR6C Model
CR6D Model
- Cooktop Model Options
