The CR6 Oven is a 490 mm (internal) full width oven
fitted with French style opening doors. The oven
burner is a 24-26 MJ oven burner and has pilot and
flame failure with piezo ignition.
The CR9 Oven is a 780 mm (internal) full width oven
fitted with French style opening doors. The oven
burner is a 28-30 MJ oven burner and has pilot and
flame failure with piezo ignition.
The Range has an easy clean stainless steel external
finish.
Part 2 Specifications
Model Covered in this Specification -
CR6D[1] Range 4 Open Burners.
CR6C[1] Range 2 Burners + 300 mm Griddle.
CR6B Range 600 mm Griddle.
CR9D[1] Range 6 Open Burners.
CR9C[1] Range 4 Burners + 300 mm Griddle.
CR9B[1] Range 2 Burners + 600 mm Griddle.
CR9A Range 900 mm Griddle.
[1] - Open Burner Options;
F - With Flame Failure Protection.
- Standard Burners.
General
A heavy duty, general purpose gas range created
for compact modular kitchens and available in a
600mm and 900mm wide option. It has a high
option Cooktop / Griddle arrangement and is
available on adjustable front feet and robust rear
rollers. Open Burners have Flame Failure Option as
standard for UK market and as an option for all
other markets.
Griddles are available in 300 mm, 600 mm and for
the CR9 Gas Static Oven Range, 900 mm options
and are fitted with pilot, flame failure and piezo
ignition as standard.
Gas Supply Requirements
- Non - UK Only:
Natural Gas (G20) Propane (G31)
Griddle
(each 300 mm
section)
Oven Open
Burner
(each)
Griddle
(each 300 mm
section)
Oven
CR6 CR9 CR6 CR9
Heat Input
(nett)
Nominal
5.0 kW 5.0 kW 6.5 kW 7.5 kW 4.6 kW 5.0 kW 6.0 kW 7.5 kW
Reduced
1.7 kW 1.5 kW 1.1 kW 2.2 kW 1.5 kW 2.2 kW 1.05 kW 2.3 kW
Gas Rate
(nett)
Nominal
0.53 m
3
/hr 0.53 m
3
/hr 0.51 m
3
/hr 0.79 m
3
/hr 0.36 kg/hr 0.39 kg/hr 0.47 kg/hr 0.58 kg/hr
Reduced
0.18 m
3
/hr 0.16 m
3
/hr 0.14 m
3
/hr 0.23 m
3
/hr 0.12 kg/hr 0.17 kg/hr 0.09 kg/hr 0.18 kg/hr
Supply Pressure
20 mbar 37 mbar
Operating Pressure
10 mbar (*) 28 mbar (*)
Gas Connection
3
/
4
” B.S.P. Male
Open
Burner
(each)
NOTE:
(
*
) The burner operating pressure is to be measured at the manifold test point with two burners operating at
full setting. The operating pressure is ex-factory set, through the appliance regulator and is not to be
adjusted, apart from when carrying out gas conversion, if required. (Refer to the ‘Gas Conversion’
Instruction Sheet for this appliance for further details).
Natural Gas LP Gas (Propane)
Open Burner
(each)
Griddle
(each 300 mm
section)
Open Burner
(each)
Griddle
(each 300 mm
section)
Oven
CR6 CR9 CR6 CR9
Input Rate
(N.H.G.C.)
22 MJ/hr 20 MJ/hr 24 MJ/hr 28 MJ/hr 22 MJ/hr 20 MJ/hr 24 MJ/hr 28 MJ/hr
Supply Pressure
1.13 - 3.40 kPa
(4.5” -13.5” w.c.)
2.75 - 4.50 kPa
(11” -18.0”w.c.)
Burner Operating
Pressure
1.0 kPa (*)
(4.0” w.c.)
2.6 kPa (*)
(10.0” w.c.)
Gas Connection
¾” BSP Male
Oven
To Next Page
