Page 14 Coby Electronics Corporation www.cobyusa.com Page 15
Page 14 Coby Electronics Corporation www.cobyusa.com Page 15
GETTING STARTED
Overview of Audio/Video Connections
S-VIDEO
Composite Video
2-Channel Audio
S-VIDEO Cable
Coaxial
Input
Amplifier with
Digital Decoding
Connect the AC power
cord to the wall outlet
AFTER all other cables
are connected.
Connect only one type
of audio or video
connection at a time to
minimize interference.
