Coby TFTV1525 User Manual

ReadInstructions:Allthesafetyandoperatinginstructionsshouldbereadbeforetheproductisoperated.1.
RetainInstructions:Thesafetyandoperatinginstructionsshouldberetainedforfuturereference.2.
HeedWarnings:Allwarningsontheproductandintheoperatinginstructionsshouldbeadheredto.3.
FollowInstructions:Alloperatingandusageinstructionsshouldbefollowed.4.
Cleaning:Unplugthisproductfromthewalloutletbeforecleaning.Donotuseliquidcleanersoraerosol5.
cleaners.Useadampclothforcleaning.
Attachments:Useonlyattachmentsrecommendedbythemanufacturer.Useofotherattachmentsmay6.
behazardous.
WaterandMoisture:Donotusethisproductnearwater(e.g.,nearabathtub,washbowl,kitchensink,7.
laundrytub,inwetbasements,ornearaswimmingpoolandthelike).
Accessories:Do notplace this producton anunstablecart,stand,tripod, bracket, ortable. Useonly8.
withcarts,stands,tripods,brackets,ortablesrecommendedbythemanufacturer
or sold withthe product.Any mounting ofthe productshouldfollow the
manufacturer’s instructions and should use a mounting accessory
recommendedbythemanufacturer.
Aproductandcartcombinationshouldbemovedwithcare.Quickstops,9.
excessiveforce,anduneven surfacesmaycausetheproduct and cart
combinationtooverturn.
Ventilation:Slotsandopeningsinthecabinetareprovidedforventilation10.
to ensure reliable operation of the product and to protect it from
overheating. These openings should never beblocked byplacing the
producton abed, sofa, rug, or other similarsurface.Thisproduct should
notbeplacedinabuilt-ininstallationsuchasabookcaseorrackunlessproper
ventilationisprovidedorthemanufacturerinstructionshavebeenadheredto.
PowerSources:Thisproduct shouldbeoperatedonlyfromthetypeofpowersourceindicatedonthe11.
ratinglabel.Ifyouarenotsureofthetypeofpowersupplytoyourhome,consultyourproductdealeror
localpowercompany.Forproductsintendedtooperatefrombatterypowerorothersources,refertothe
operatinginstructions.
GroundingorPolarization:Thisproductmaybeequippedwithapolarizedalternating-currentlineplug12.
thathasonebladewiderthantheother.Thisplugwillonlytintothepoweroutletinonedirection.This
isasafetyfeature.Ifyouareunabletoinserttheplugfullyintotheoutlet,tryreversingthedirectionofthe
plug.Iftheplugshouldstillfailtot,contactanelectriciantoreplacetheobsoleteoutlet.Donotdefeat
thesafetypurposeofthepolarizedplug.
Power-CordProtection:Powersupplycordsshouldberoutedsothattheyarenotlikelytobewalked13.
on orpinchedby items placed upon oragainstthem, paying particular attention to cordsat plugs,
conveniencereceptacles,andatthepointwhichtheyexitfromtheproduct.
ProtectiveAttachment Plug:The product may beequippedwith an attachment plug with overload14.
protection.This is a safetyfeature. See theoperatinginstructionsfor replacement or directionsto
resetthe protectivedevice.If replacementoftheplug isrequired,besuretheservicetechnicianhas
usedareplacementplugthathasthesameoverloadprotectionastheoriginalplugasspeciedbythe
manufacturer.
Lightning:Foraddedprotectionforthisproduct,unplugitfromthewalloutletanddisconnecttheantenna15.
orcablesystemduringalightningstormorwhenitisleftunattendedandunusedforlongperiodsoftime.
Thiswillpreventdamagetotheproductduetolightningorpower-linesurges.
PowerLines:Anoutsideantennasystemshouldnotbelocatedinthevicinityofoverheadpowerlinesor16.
otherelectriclightorpowercircuits,orwhereitcanfallintosuchpowerlinesorcircuits.Wheninstalling
anoutsideantenna system,extremecareshouldbetakentokeep fromtouchingsuchpowerlinesor
circuits,ascontactwiththemmightbefatal.
Overloading:Donotoverloadwalloutlets,extensioncords,orintegralconveniencereceptaclesasthis17.
canresultinariskofreorelectricshock.
ObjectandLiquidEntry:Neverpushobjectsofanykindintothisproductthroughopeningsastheymay18.
touchdangerousvoltagepointsorshout-outpartsthatcouldresultinareorelectricshock.Neverspill
liquidofanykindontheproduct.
Servicing:Donotattempttoservicethisproduct yourselfasopening orremovingcoversmayexpose19.
youtodangerousvoltageorotherhazards.Referallservicingtoqualiedservicepersonnel.
Important Safety Instructions

Coby TFTV1525 Specifications

General

3D	No
Pixel pitch	0.252 x 0.252 mm
Response time	8 ms
Display diagonal	15.6 \
Display brightness	220 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Supported video modes	1080i, 1080p, 480i, 480p, 720p
Display number of colors	262144 colors
Supported graphics resolutions	1366 x 768
Operating temperature (T-T)	0 - 40 °C
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, FRE
Certification	ETL, FCC, HDMI
Composite video out	0
Digital audio optical out	1
Product color	Black
Panel mounting interface	75 x 75 mm
Package depth	160 mm
Package width	419 mm
Package height	378.5 mm
Cables included	AV
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	40 W
RMS rated power	3 W
Number of speakers	2
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC

Weight and Dimensions

Depth (with stand)	134.6 mm
Width (with stand)	346 mm
Height (with stand)	353 mm
Depth (without stand)	63.5 mm
Height (without stand)	300 mm
