Figure. Cable connections
Antenna/Power Connection
ConnectTVRFsourcestotheantennaport.TVRFsignalsinclude:receivingantenna/CATVnet.You1.
canuse75Ohmcoaxialcabletoconnectoutdoorantenna.
Insertoneendofthesuppliedpowercordtotheplayer’spowerjackandtheotherendtothe110-240V2.
ACwalloutlet.
VGA Input - PC Connection
TheVGAportoftheTViscapable ofacceptinghigh-denitionsignalsfromcomputerswithaVGAoutput
jack.Whenusedasacomputermoniter,connecttheVGAjackandthePCAudioInjackwitha15-PinD-Sub
cableanda3.5mmstereoaudiocable.
Coaxial Output - Digital Audio Output Connector
WhenMPEG audioorDolby Digitalaudio isplayed, DolbyDigital bitstream orMPEG audiobitstream is
senttotheplayer’sdigitalaudiooutputconnector.WhentheplayerisconnectedtoaDolbyorMPEGaudio
decorderviathisoutputsocket,youcanenjoytheater-qualityaudioinyourhome.Anopticalaudiocableis
requiredwhenaDolbyDigitaldecoderorMPEGaudiodecoderisused.
Phone Connection
Be surethatyourunitis setat a lowvolume levelbeforeconnectingthe earphone.Increasethevolume
graduallyforyourcomfortablelistening.
CAUTION:
Hearingexpertsadviseagainsttheconstantuseofpersonalstereosplayedathighvolume.Constanthigh
volumeusecanleadtohearingloss.Ifyouexperienceringingintheearsorhearingloss,discontinueuse
andseekmedicaladvise.
HDMI Input - AV Signal Input
HDMI(HighDenitionMultimediaInterface)isanewtypeofconnectionthattransmitsdigitalaudioandvideo
signalssimultaneouslyoverasinglecable.AHDMIcableisrequiredfortheHDMIconnection.
TheseHDMIinputconnectorsarecapableofreceivingvideoatresolutionsupto1080p(1080-progressive).
Cable Connections
External AV Source
Amplifier equipped with a Dolby
Pro Logic Surround
>
Wall Outlet
Settheunitinto therelativeinput mode toenablethe
signalpass.
