Follow the guide below for information on repair and trouble shooting for the arrowstik option.
ARROWSTIK
®
OPTION
TROUBLESHOOTING GUIDE
PROBLEM
Arrowstik does not
function when
turned on.
Lamp or LED
module does not
come on when it
should.
POSSIBLE CAUSE
a. Check plug in rear of
control box.
a. Check power and ground
connections.
a. Bad lamp or defective
LED module.
b. Defective wiring connection.
a. Control box is damaged.
SOLUTION
a. Reconnect plug.
a. Reconnect ground/power.
a. Replace lamp or LED
module.
b. Repair connection.
c. Return to Code3.
QUESTIONS
Are the front
panel LED
indicators
operating
properly?
Yes
No
Are the front
panel LED
indicators
functioning
properly?
Yes
No
Note: LED modules have no user serviceable parts. Replace entire module if
found defective.
