5
FIGURE 4
Attaching the pivot arm brackets
Attach the passenger side outer brackets that are supplied noting the difference between passenger and
driver side brackets. Slide the bracket in place using the notch in the bracket to clear the attached wire as
show in Figure 4. Position the bracket on the passenger sun visor's pivot arm and verify the orientation of
the bracket as shown in Figure 5. Attach the phillips screws as shown in Figure 6. Repeat this operation
for the driver side sun visor and outer bracket.
FIGURE 5
