Code 3 Z3 Series User Manual

20
Ref No. Description Purchasable Part No. Internal Part No. (Not For Sale) Qty.
1 Amplier E Tray T15305 All Amplier Components 1
2 Amplier PCB T11851 Are Purchasable 1
3 #6-32 X .375” Phil Pan HD MS T04250 1
4 #6-32 X 1.875” Hex MF Stdoff T15326 2
5 Outputs & Dim Int Harness T56632 3
6 Light Board PCB T11854 1
7 I2C Comm Cable T56623 1
8 #6-32 X .250 Phil Pan HD MS T07077 3
9 Amplier Cover T15307 1
10 Amplier Fuse Cover T15310 1
11 #8-32 X .250 Phil Pan HD TRS T09751 2
12 Warning Label T09937 1
13 Wiring Label Fuse Map T11861 1
14 Wiring Label Amp Box Top T11863 1
15 #6-32 X 2.250 Phil Pan HD MS T15328 3
16 Washer, Int Tooth #6 T00150 1
17 #6-32 X 1.500 Phil Pan HD MS T01332 1
18 Wiring Label, Terminal Side T11863 1
To order a complete Siren Amplier, order part number S39285M.
To order a complete Siren Cable & Harness bag, order part number T56641.
To order a complete Siren Manuals & Legends bag, order part number S38284M.
Siren Amplier, Parts List
