4.4 WM-180° Wall Mount Speaker Installation
4.4.1 Tools Required
Ladder – to reach mounting height.
Security bit - to remove phone to access mounting holes.
½-inch concrete bit – to drill holes for the mounting anchors for the mounting bolts.
9/16” socket set - to secure the housing to the wall with mounting bolt.
Note: If unit does not include an IP or Analog controller board, then it
must be located near an IA4100 or IP5000 speakerphone for the 20-
foot supplied PAS cables to reach it.
*See included drawing for anchor bolt and conduit locations.
4.5 Installation with Controller Board
4.5.1.1 Supply 24V AC to Power Manifold (see Figure on Page 22).
4.5.1.2 Supply phone line to phone port if the unit has an analog controller board, or
Ethernet IP connection to LAN port if it has an IP controller board.
4.5.1.3 Reference IA4100 Admin and User Guide for analog controller board
programming.
4.5.1.4 Reference IP5000 Admin and User Guide for IP controller board programming.
4.5.1.5 Code Blue guides are located at codeblue.com > support > downloads.
4.6 Installation without Controller Board
4.6.1.1 Supply 24V AC to Power Manifold.
4.6.1.2 See attached wiring diagram for connecting the PAS Audio Cable and PAS
Control Cable to the nearby IA4100 or IP5000 speakerphone.
4.6.1.3 Reference IA4100 Admin and User Guide for analog controller board
programming.
4.6.1.4 Reference IP5000 Admin and User Guide for IP controller board programming.
