IA4100
Administrator Guide
Programming Commands (continued)
Programming Buttons and Inputs
Command Explanation Format Default
31
Button 1 (RED)
31<phone number>
Ý<output(s)>Ý<recording(s)># 123Ý13Ý1#
32
Button 2 (BLACK) 32<phone number>
Ý<output(s)>Ý<recording(s)># 0456Ý2Ý#
33
Button 3
33<phone number>
Ý<output(s)>Ý<recording(s)># ÝÝ#
34
Button 4
34<phone number>
Ý<output(s)>Ý<recording(s)># ÝÝ#
35 Input 1 35<button># 0#
36 Input 2 36<button># 0#
37
Loss of
AC power
37<phone number>
Ý<output(s)>Ý<recording(s)># 7ÝÝ7#
38
Low battery
38<phone number>
Ý<output(s)>Ý<recording(s)># 8ÝÝ8#
39
P
AS Fault
39<phone number>
Ý<output(s)>Ý<recording(s)># 9ÝÝ9#
NOTES: For Programming Phone Numbers, see Commands 01 to 09 (page 5).
If the rst phone number slot entered is zero and a keypad (i.e., FP2-K faceplate) is
connected, then this button (other than RED) will activate as manual call mode. Or if
entering a number slot (e.g., 31123ÝÝ# or 32456ÝÝ#) has a phone number pro-
grammed and a keypad is present, the number will be auto dialed. Upon the call being
detected and answered by voice message (auto attendant), the user is allowed keypad
access to dial a number allowed by system.
For setting outputs 1 through 3 on, see Programming Outputs, Commands 11 to 13 (page 5).
For recorded messages, see Programming Recordings 1 through 9, see Commands 21 to 29
(page 5).
A message will play over the speaker immediately after a button press in the order in
which they were programmed.
For Input Commands 35 and 36, the input associated with the button is as follows:
0 = disabled
1 to 4 = button 1 to 4
Voltage controlled relays = 9-32 volts AC or DC
(Continued on next page)
