6.1 Raw Data
Reader to Host communication consists of decoded raw data having no framing or check characters.
Raw data is sent with no “end of packet” data (crc16), expects no response from Host and no data is
resent.
6.2 Packet Data
Data from the Reader to the Host consist of packets as specified below. Packetized data is sent using
ACK/NAK protocols with framing and check characters. Packets are delivered asynchronously as
barcodes are read and in response to Host to Reader commands. For keyboard communication (USB
keyboard), all ASCII-characters are transmitted as keyboard-sequences. For all other communication
ports, all ASCII-characters are transmitted as ASCII-bytes.
Note: Even though the data size field allows up to 65535 bytes of data in a packet, the actual size of a
packet either in raw or in packet mode including data and packet overhead is a maximum of 16384
bytes.
Note: The following acronyms from the ASCII character definitions are used below:
 SOH – Start of Heading (0x01)
 STX – Start of Text (0x02)
 EOT – End of Transmission (0x04)
 RS – Record Separator (0x1E)
Language Part
Definition
packet
start packet-type
nz
data
opt
end
start
packet-start
nr
| codeXML-start
nz
packet-start
SOH ‘X’ ‘R’ protocol-version Reader-id packet-number timestamp data-size
protocol-
version
‘1’
Reader-id
big-endian 32-bit number
packet-number
data-packet-number | cmd-packet-number
data-packet-
number
any byte value in the range [0,7f]; increments with each packet; does not increment with
resends; used with z and a packets only
cmd-packet-
number
any byte value in the range [80-ff]; increments with each packet; does not increment with
resends; used with all packets other than z and a
timestamp
big-endian 32-bit number, indicates timestamp in seconds (relative to Reader power-up)
(For all but z packets, the timestamp represents the time the packet was sent to the Host;
for z packets, the time the barcode was read.)
data-size
big-endian 16-bit number indicating size of the data field (in bytes)
codeXML-start
SOH ‘X’ RS tag_response ‘/’
tag_response
‘ap’
packet-type
Single ASCII-character in table below
