13.0 - CR5000 Overall Dimensions
3.55"
(90.30 mm)
2.80"
(71.23 mm)
5.95"
(151.14 mm)
14.0 - USB Cable Example with Pinouts
NOTES:
1. Part to be ROHS and Reach compliant.
2. Maximum Voltage Tolerance = 5V +/- 10%.
3. Caution: Exceeding the maximum voltage will void
manufacturer warranty.
CONNECTOR A CONNECTOR B
CONNECTOR A NAME WIRE COLOR CONNECTOR B
1 VIN 24AWG RED 1
2 DM 26AWG WHITE 2
3 DP 26AWG GREEN 3
4 GND 24AWG BLACK 10
SHELL - SHIELD BARE SHELL
