C001537_04_CR2 User Manual - 8
Save Settings
2.1 - Installation Guide - USB Interface
To connect the CR2 to your host computer via USB interface:
1. Make sure the USB cable is sufficiently
attached to your CR2 unit (figure 2.1).
2. You DO NOT need to power off your host
computer (figure 2.2). The CR2 with USB
interface can be plugged into any host while
the computer is powered up.
3. Connect the USB interface cable to the host (figure 2.3). If you are unsure of
the proper location to connect the USB cable please consult the manual of
your host computer.
4. The USB interface does not require additional power supply. If you are using
the 1400 mAH or 1950 mAH battery for batch mode, the CR2 will automatically recharge
the battery whenever the unit is a attached to a host that is powered up.
5. The CR2 will power on automatically.
6. Scan the USB Keyboard Mode code to then the Save Setting code to configure reader:
USB Keyboard Mode Save Settings
Note: For more information on other USB modes, please see section 5.2 of the CR2 Users
Manual
7. Your CR2 unit should be ready for use. Open the application you wish to send data and
begin scanning.
Figure 2.1
Figure 2.2
Figure 2.3
