If your lock case has a hole below the follower
(Figure 1 ‘A’), proceed as follows:
Hold the neoprene seal with the three holes against
the door, perfectly vertically, with the rectangular hole
centrally over the follower, mark the top and bottom holes
on the door face, and repeat the procedure on the other
side of the door. Remove the lock. At both points drill a
10mm (
3
/
8
”) hole through the door. Drill from both sides
for greater accuracy and to avoid splintering out of the
door face. Check that the existing spindle hole is at least
18mm (
11
/
16
”) diameter. Replace the lock.
STEP 1
STEP 2
STEP 3
For door hung on RIGHT fit silver spindle
on code side.
For door hung on LEFT fit coloured spindle
on code side.
Fit the butterfly spindle to the inside,
non-code side.
Note: Front plate supplied set up for Right
Hand doors, viewed from code side. N/A for CL500
KEY models
Check that the lever handles are correctly orientated
for the hand of door. To change the hand of a lever
handle proceed as follows:
1. Code Side Lever
• Remove blue handing screw from position ‘R’ (Fig 1).
• Back off the two silver colour screws at the bottom
of the lock one full turn each.
• Force handle through 180° to preferred orientation.
The clutch will pop through twice to achieve this.
• Secure the two silver colour screws back a full turn.
• Replace blue handing screw in position ‘L’ (Fig 2).
2. Back Plate Lever
• Turn handle to preferred orientation.
• Fit spindle drive assembly (number 15 in contents).
• Fit 2 fixing screws.
Lock is now set up for a door hung on left.
