APPENDIX Product Specifications
G500 Series
Appendix_ Product Specifications
042
Dimension
Length 11.2” (285 mm)
Height 6.8” (171 mm)
Width 8.9” (226 mm)
Weight 6 lbs (2.72Kg) ,excluding consumables
Options
Cutter Module
Label Dispenser (peel)
External label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder
i
>>> Specifications are subject to change without notice. All company and/or product names are trademarks and/or
registered trademarks of their respective owners.
>>> Minimum print height and maximum print speed specification compliance can be dependent on non-standard
material variables such as label type, thickness, spacing, liner construction, etc. Godex is pleased to test
non-standard materials for minimum print height and maximum print speed capability.
Model G500 G530
APPENDIX Interface
G500 Series
Appendix_ Interface
043
Pinout description
 Parallel Port
Handshaking: DSTB is sent to the printer, BUSY to the host computer.
Interface Cable: Parallel cable compatible with IBM computers.
Pinout: See below.
 Serial Port
Default Settings: Baud rate 9600, no parity, 8 data bits, 1 stop bit, XON/XOFF protocol and RTS/CTS.
 USB
Connector Type : Type B
Pin NO.
Function
Transmitter
1
2-9
10
11
12
13
14
15
16
17
18
19-30
31
32
33-35
36
/Strobe
Data 0-7
/Acknowledge
Busy
/Paper empty
/Select
/Auto-Linefeed
N/C
Signal Gnd
Chasis Gnd
+5V,max 500mA
Signal Gnd
/Initialize
/Error
N/C
/Select-in
host / printer
host
printer
printer
printer
printer
host / printer
host
host / printer
printer
host / printer
RS232 HOUSING (9-pin to 9-pin)
DB9 Socket
DB9 Plug
---
1 1
+5V,max 500mA
RXD
2 2
TXD
TXD
3 3
RXD
N/C
4 4
N/C
GND
5 5
GND
DSR
6 6
RTS
RTS 7 7
CTS
CTS
8 8
RTS
N/C
9 9
N/C
PC
Printer
Pin NO.
1
2
3
4
Function
VBUS D- D+ GND
