2 Printer Setup

G500 Series

Loading The Label Roll

 A New Label Roll Module Installation

Place the label stock on the label supply hub, attach the guide plates to the label stock holder.

 Install The Label Roll Module On The Printer

Now load the label stock into the printer.

2-4

Place on the ribbon hub

LABEL STOCK

LABEL SUPPLY HUB

LABEL GUIDE PLATES

Place on the printer

Printer Setup
