1.6- Accessories.
1.6.1- PC Keyboard
The control panel Compact Lyon system allows a standard PC keyboard to be connected, with PS2
connector (minidin6), thereby enabling the programming and the labelling of zones, elements and relays.
1.6.2- PC based configuration software.
Software is available for the digital control panel Compact Lyon (EasyConet), that means of which
the user can perform all the control panel programming in a simple and intuitive way. With this system it
will be possible to maintain the configuration for future use.
The minimum configuration of the PC is:
Pentium IV
Windows XP SP2
128 Mbytes of RAM
50 Mbytes free space on the hard disk
CD-ROM
Minimum resolution 1024 x 768
Free USB port
2- Installation
2.1- Control panel installation.
The control panel must be assembled on a vertical face. The lateral grooves in the control panel must
be left free for correct heat evacuation. The dimensions and pre-drilling for the cable input are in the
following figure.
Figure 14. Control panel Compact Lyon box
