 Disabled zones and elements
In the case of disabling a elements or zone, the control panel will illuminate the amber DISABLED
LED, sound the buzzer and show the following message:
C
ANCELED TYPE :
01>LABEL POI NT CANCEL
02 LABEL ZONE CANCEL
>> 01
⁄
02
If the right cursor is pressed, we will be able to see the rest of the zone and/or element information.
Unit Loop Point
C
ANCELED C:B:Pt:
01>Z:001 LABEL 01 01 001
02 Z:001 LABEL - - - - - - -
<< 01
⁄
02
Cancel selected Cancel
 Power supply faults
If the control panel detects a power supply failure, it will illuminate the amber GENERAL FAULT
and SUPPLY FAULT LEDs, sound the buzzer and show the following message.
F
AULTS TYPE :
01>SUPPLY CONTROL EMPTY BAT .
0 2 SUPPLY CONTROL H I GH V NET
>> 01
⁄
02
Within supply faults, the following types of fault exist:
Type of Fault Description
30V
Fault in the 30V output
NO BATTERY
Battery fault due to or absence of batteries
CHARGER FAULT
Battery charger fault
BAT DISCHARGED
Battery fault due to low Voltage level
BAT OVERCHARGED
Battery fault due to high Voltage level.
HIGH VOLTAGE
Network Voltage fault due to exceeding the level
LOW VOLTAGE
Network Voltage fault due to low level or absence of the same
 POINT faults
If the control panel detects a fault in any of the elements, it will illuminate the amber GENERAL
FAULT LED, sound the buzzer and show the following message.
F
AULTS TYPE :
01>LABEL PNT NO ANS
W
ER
02 LABEL CC RELAY 02
>> 01
⁄
02
N relay
