OPERATOR INFORMATION
Accessing the Service Menu
Dishwasher-safe parts list
Open the door, remove the rubber cover and insert the
Operator USB stick into the USB port (see Fig. 1).
Within a few seconds the Service Menu will display on the
touchscreen (see Fig. 2), then enter the PIN code if required
(see Fig. 3).
Press the desired button to access the function needed.
Follow the on screen instructions to complete each
function.
To exit the service menu simply remove the USB stick and
replace the rubber cover on the USB port
Close and lock the door, then press EXIT on the
touchscreen to return to the home screen.
These parts can be washed in a residential grade dishwasher (with water temperature note exceeding 70ºC):
• Mixer bodies
• Mixer mounting plates
• Mixing bowls
• Whipper discs
• Coffee and drink outlet funnels
• Brew chamber and steam trap
• Canisters bodies
• Canister chutes
• Cup slider liners
01
02
02
03
03
03
Important:
Never close the door with a USB key still inserted
into the door USB port, it may cause damage to the
USB key, USB port or PCB.
