Specifications
The following sections list general specifications for the reader.
DataMan 380 Series Reader
Specification DataMan 380
Lens Type C-Mount lens or Cognex High Speed Liquid Lens
Trigger 1 opto-isolated, acquisition trigger input.
Discrete Inputs 1 opto-isolated, acquisition trigger input.
Up to 3 general-purpose inputs when connected to the Breakout cable.
V
IL
: ≤ ± 6 V
V
IH
: ≥ ± 12 V
I
TYP
: 4.2 mA @ 24 V
Discrete Outputs Up to 4 outputs when connected to the Breakout cable.
I
MAX
: 50 mA
V
OL
: ≤ ± 3 V @ 50 mA
Status LEDs Pass/Fail LED and Indicator Ring, Network LED, and Error LED.
Codes 1-D barcodes: Codabar, Code 39, Code 128, Code 93, Code 25, Interleaved 2 of 5,
UPC/EAN/JAN
2-D barcodes: Data Matrix (ECC 0, 50, 80, 100, 140, and 200), QR Code, PDF 417, MaxiCode
Network Communication 2 Ethernet ports, 10/100/1000 BaseT with auto MDIX. IEEE 802.3 TCP/IP Protocol.
Supports DHCP, static, and link-local IP address configuration. One port supports TSN networks.
RS-232: RxD, TxD according to TIA/EIA-232-F
Power Consumption 24 V DC +/- 10%
LPS or NEC class 2
Power consumption without USB device attached:
l
Average ≤ 15 W without illumination
l
Average ≤ 40 W with illumination
l
Peak ≤ 2 A
Power Output 24 V DC at 1.0 A maximum to external light.
Material Die-cast and extruded aluminum and zinc housing.
Finish Painted.
Mounting Four M3 threaded mounting holes. See Mounting Brackets on page9 for supported mounts.
Pattern: 38.5 × 58.5 mm (1.52 × 2.60 in)
35
