Cold Jet i3 MICROCLEAN - Symbol Glossary; Operation Symbols

34
34
OM.MC.20160506
The i
3
MicroClean uses ISO safety symbols. The symbols come in three categories:
1. A yellow warning triangle/black graphical symbol indicates what the hazard is.
2. A blue mandatory action circle/white graphical symbol indicates an action to
take to avoid the hazard.
3. A red circle-with-slash/black graphical symbol indicates a prohibited action to
avoid the hazard.
All symbols may not apply to the i
3
MicroClean.
IN THIS SECTION
Operation Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . 34
Yellow Warning Symbols. . . . . . . . . . . . . . . . . . . . 35
Blue Mandatory Symbols . . . . . . . . . . . . . . . . 35
Red Prohibited Action Symbols . . . . . . . 35
SYMBOL GLOSSARY
OPERATION SYMBOL
On
OPERATION SYMBOL
Hour Meter
OPERATION SYMBOL
Off
OPERATION SYMBOL
Air Bleed
OPERATION SYMBOL
Variable Dry Ice
Feed Rate
OPERATION SYMBOL
Applicator Light
OPERATION SYMBOL
Regulated
Air Pressure
OPERATION SYMBOL
Reset
OPERATION SYMBOL
Trigger Disable
OPERATION SYMBOL
CO
2
Only
