Cold Jet i3 MICROCLEAN - Specifications

5
OM.MC.20160506
The single hose electric i
3
MicroClean features Cold Jet’s patented shaved dry ice
technology, providing unparalleled precision and reliability. This environmentally
responsible system enables you to safely clean delicate surfaces and complex cavities
and crevices that other machines can’t reach—without surface abrasion, disassembly
or harmful secondary waste.
IN THIS SECTION
Specifications. . . . . . . . . . . . . . . 5
Unit Operation. . . . . . . . . . . 11
Maintenance. . . . . . . . . . . 15
Troubleshooting. . . . . 16
SPECIFICATIONS
Weight (empty) 130lb (59kg)
Dimensions 22 x 16 x 21in (56 x 41 x 53cm)
Dry Ice Capacity
6 x 6 x12in (150 x 150 x 300mm) (24.5lbs./11kg)
5 x 5 x 12in (127 x 127 x 300mm)
with inserts (16.5 lbs. 7.5 kg.)
Variable Feed Rate 0 - 1.2 lbs/min (0-0.6 kg/min)
Power Consumption
100 - 140 VAC 1 Ø 60 Hz 300W (watts)
200 - 240 VAC 1 Ø 50 Hz 300W (watts)
Feeder Drive 1/4 Hp, 1.1 A, 230 VAC, 1, 750 RPM, AC Motor
Blast Pressure Range 20 - 140 psig (1.4 - 9.7 bar)
Supply Pressure Range 50 - 140 psig (3.4 - 9.7 bar)
Air Consumption
Range
12 – 50 scfm @ 100 psig (0.3 – 1.4 m3/min @ 6.9 bar)
Dependent on nozzle selection
A-Weighted Emission
Sound Pressure
Level Range
84 (distance of 10 ft.) – 97 dbA (distance of 2 ft.)*
* Nozzle 13865-259 @ 80 PSI blast pressure
Weight (empty) 130lb (59kg)
Dimensions 22 x 16 x 21in (56 x 41 x 53cm)
Dry Ice Capacity
6 x 6 x12in (150 x 150 x 300mm) (24.5lbs./11kg)
5 x 5 x 12in (127 x 127 x 300mm)
with inserts (16.5 lbs. 7.5 kg.)
Variable Feed Rate 0 - 1.2 lbs/min (0-0.6 kg/min)
Power Consumption
100 - 140 VAC 1 Ø 60 Hz 300W (watts)
200 - 240 VAC 1 Ø 50 Hz 300W (watts)
Feeder Drive 1/4 Hp, 1.1 A, 230 VAC, 1, 750 RPM, AC Motor
Blast Pressure Range 20 - 140 psig (1.4 - 9.7 bar)
Supply Pressure Range 50 - 140 psig (3.4 - 9.7 bar)
Air Consumption
Range
12 – 50 scfm @ 100 psig (0.3 – 1.4 m3/min @ 6.9 bar)
Dependent on nozzle selection
A-Weighted Emission
Sound Pressure
Level Range
84 (distance of 10 ft.) – 97 dbA (distance of 2 ft.)*
* Nozzle 13865-259 @ 80 PSI blast pressure
