These low voltage controllers are capable of operating
both the roof top air conditioner and any furnace with a
12 VDC control circuit of 1 amp or less (continuous
current).
All air conditioning equipment is subject to freeze up
when evaporator air flow is sufficiently reduced. Ducting
of any length creates potential for reduced evaporator air
flow and system freeze up. To protect both the installer
and Airxcel, Inc. from conditions that promote reduced
air flow and system freeze up, Airxcel, Inc. has equipped
the ceiling plenum compressor control circuit with a low
temperature probe. The low temperature probe monitors
the temperature of the air conditioner evaporator coil.
When the temperature of the evaporator coil drops below
28 degrees F, the switch will open, stopping compressor
operation. Compressor operation will resume once the
evaporator warms to 55 degrees F.
IMPORTANT
The low temperature sensor is part of the ceiling
plenum electrical circuit. The probe must be inserted
into the evaporator coil of the roof top unit by the
installer when bolting the ceiling plenum to the roof
top unit.
3. PACKAGE CONTENTS
The mounting kit package contains the following:
1) Steel mount frame
2) Ceiling shroud assembly
3) Small parts package consisting of:
a) Mounting bolt (x4)
b) Mount screws (x3)
c) Supply duct assembly
d) Shoulder screw/spring (x4)
4. SYSTEM MATCH-UP
Ceiling Assembly Control Box Wall
Desired Function Kit Thermostat
12 VDC Control 8330-752 7330G335
Cooling Only or 8330-336
12 VDC Control 9330C755 7330G335
Cool/Heat Ready or 8330-336
24 VAC Control 8530-750 7330B344
Cooling Only or 8330B324
12 VDC Control 9530A751 8530A345
Heat Pump
Ceiling Assembly Control Box Wall
Desired Function Kit Thermostat
12 VDC Zone
Control Cooling 9430A751 9330A335
Only
12 VDC Zone
Control 9430A755 9330A335
Cool/Heat Ready
12 VDC Zone
Control Heat 9630A751 9330A335
Pump
