WARNING
z The fuel tank supplied with this engine could only be used as supply of fuel for its running and
must not be as a fuel storage container.
z The fuel cock must be at close position while using portable fuel tank.
z Disconnect the fuel joint while using the built-in fuel tank.
1.2 General information
1.2.1 Specifications
Parameter
Items Data Items Data
Type of engine 4-stroke S Weight (L) 25.5Kg
Displacement 112cm
3
Recommended fuel Unleaded regular gasoline
Bore X stroke 59mm×41mm Built-in fuel tank capacity 1.3L
Gear ratio 2.08（27/13） Recommended engine oil SAE10W30 orSAE10W40
Overall length 717mm Engine oil quantity 0.5L
Overall width 361mm Recommended gear oil Hypoid gear oil SAE﹟90
Overall height (S) 1029mm Gear oil quantity 100cm
3
Overall height (L) 1156mm Spark plug BR6HS
Weight (S) 24.5Kg Spark plug gap 0.6～0.7mm
3
