Coleman TH4B6021S - Page 12

5005749-CTG-A-0216
12 Johnson Controls Unitary Products
TH4B2421S TMLV060A12MP11 14.5 CF/CM/CU30A 725 24.0 16.9 15.75 12.75 23.8 15.5 8.50 3.78 2.58 22.1 20.0
TH4B2421S TMLV080B12MP11 17.5 CF/CM/CU24B 675 23.6 15.9 15.00 12.50 23.2 15.0 8.25 3.52 2.40 22.3 19.9
TH4B2421S TMLV080B12MP11 17.5 CF/CM/CU30B 800 24.0 17.4 15.75 13.00 24.0 15.5 8.50 3.88 2.60 21.8 19.7
TH4B2421S TMLX060A12MP11 14.5 CF/CM/CU24A 800 24.0 17.1 15.25 12.75 23.6 15.0 8.50 3.70 2.44 21.8 19.3
TH4B2421S TMLX060A12MP11 14.5 CF/CM/CU30A 700 24.0 16.6 16.00 13.00 23.6 15.3 8.50 3.82 2.62 22.2 20.1
TH4B2421S TMLX080B12MP11 17.5 CF/CM/CU24B 725 23.6 16.5 15.50 12.75 23.2 14.9 8.50 3.62 2.46 22.1 19.9
TH4B2421S TMLX080B12MP11 17.5 CF/CM/CU30B 725 24.0 16.9 16.00 13.00 23.6 15.3 8.50 3.88 2.64 22.1 20.1
TH4B2421S TMLX080C16MP11 21.0 CF/CM/CU24C 800 24.0 17.2 15.75 13.00 23.4 14.9 8.50 3.74 2.46 21.8 19.4
TH4B2421S TMLX080C16MP11 21.0 CF/CM/CU30C 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.6
TH4B2421S TMLX080C16MP11 21.0 CF/CM/CU30D 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.6
TH4B2421S TMLX100C16MP11 21.0 CF/CM/CU24C 800 24.0 17.2 15.75 13.00 23.4 14.9 8.50 3.74 2.46 21.8 19.5
TH4B2421S TMLX100C16MP11 21.0 CF/CM/CU30C 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.5
TH4B2421S TMLX100C16MP11 21.0 CF/CM/CU30D 800 24.0 17.4 16.00 13.00 23.8 15.3 8.50 4.00 2.68 21.8 19.5
TH4B2421S TMLX100C20MP11 21.0 CF/CM/CU30C 800 24.0 17.3 15.25 12.50 24.0 15.7 8.50 3.80 2.56 21.8 19.5
TH4B2421S TMLX100C20MP11 21.0 CF/CM/CU30D 800 24.0 17.3 15.25 12.50 24.0 15.7 8.50 3.80 2.56 21.8 19.5
TH4B2421S TMLX120C20MP11 21.0 CF/CM/CU30C 800 24.0 17.3 15.25 12.50 24.0 15.7 8.50 3.80 2.56 21.8 19.5
TH4B2421S TMLX120C20MP11 21.0 CF/CM/CU30D 800 24.0 17.3 15.25 12.50 24.0 15.7 8.50 3.80 2.56 21.8 19.5
TH4B2421S TP9C060B12MP12 17.5 CF/CM/CU24B 800 24.0 17.2 15.75 13.00 23.4 14.8 8.50 3.76 2.48 21.9 19.5
TH4B2421S TP9C060B12MP12 17.5 CF/CM/CU30B 650 24.0 16.2 15.75 13.00 23.6 15.3 8.50 3.70 2.56 22.2 20.1
TH4B2421S TP9C080B12MP12 17.5 CF/CM/CU24B 800 24.0 17.2 15.75 13.00 23.4 14.8 8.50 3.76 2.48 21.8 19.4
TH4B2421S TP9C080B12MP12 17.5 CF/CM/CU30B 650 24.0 16.2 15.75 13.00 23.6 15.3 8.50 3.70 2.56 22.4 20.3
TH4B2421S TPLC060A12MP12 14.5 CF/CM/CU24A 725 23.6 16.4 14.75 12.25 23.4 15.1 8.25 3.54 2.40 21.8 19.4
TH4B2421S TPLC060A12MP12 14.5 CF/CM/CU30A 725 24.0 16.9 15.75 12.75 23.8 15.5 8.50 3.78 2.58 22.4 20.3
TH4B2421S TPLC080B12MP12 17.5 CF/CM/CU24B 675 23.6 15.9 15.00 12.50 23.2 15.0 8.25 3.52 2.40 22.3 19.9
TH4B2421S TPLC080B12MP12 17.5 CF/CM/CU30B 800 24.0 17.4 15.75 13.00 24.0 15.5 8.50 3.88 2.60 21.8 19.7
TH4B2421S CP9C060B12MP12 17.5 CF/CM/CU24B 800 24.0 17.2 15.75 13.00 23.4 14.8 8.50 3.76 2.48 21.9 19.5
TH4B2421S CP9C060B12MP12 17.5 CF/CM/CU30B 650 24.0 16.2 15.75 13.00 23.6 15.3 8.50 3.70 2.56 22.2 20.1
TH4B2421S CP9C080B12MP12 17.5 CF/CM/CU24B 800 24.0 17.2 15.75 13.00 23.4 14.8 8.50 3.76 2.48 21.8 19.4
TH4B2421S CP9C080B12MP12 17.5 CF/CM/CU30B 650 24.0 16.2 15.75 13.00 23.6 15.3 8.50 3.70 2.56 22.4 20.3
TH4B2421S CPLC060A12MP12 14.5 CF/CM/CU24A 725 23.6 16.4 14.75 12.25 23.4 15.1 8.25 3.54 2.40 21.8 19.4
TH4B2421S CPLC060A12MP12 14.5 CF/CM/CU30A 725 24.0 16.9 15.75 12.75 23.8 15.5 8.50 3.78 2.58 22.4 20.3
TH4B2421S CPLC080B12MP12 17.5 CF/CM/CU24B 675 23.6 15.9 15.00 12.50 23.2 15.0 8.25 3.52 2.40 22.3 19.9
TH4B2421S CPLC080B12MP12 17.5 CF/CM/CU30B 800 24.0 17.4 15.75 13.00 24.0 15.5 8.50 3.88 2.60 21.8 19.7
TH4B3021S TM8V060A12MP11 14.5 CF/CM36A 975 28.8 21.2 14.25 12.00 29.4 19.8 8.75 3.80 2.66 26.3 23.7
TH4B3021S TM8V080B12MP11 17.5 CF/CM/CU36B 1025 29.2 21.8 14.75 12.50 29.4 19.7 8.75 3.86 2.70 26.6 23.8
TH4B3021S TM8V080B12MP11 17.5 CF42B 1000 29.4 21.8 15.00 12.50 29.0 19.3 8.75 3.86 2.66 27.0 24.0
TH4B3021S TM8V080C16MP11 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 3.88 2.76 26.4 23.5
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
