Coleman TH4B6021S - Page 13

5005749-CTG-A-0216
Johnson Controls Unitary Products 13
TH4B3021S TM8V080C16MP11 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 3.92 2.72 27.3 24.4
TH4B3021S TM8V100C16MP11 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 3.88 2.76 26.4 23.5
TH4B3021S TM8V100C16MP11 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 3.92 2.72 27.3 24.4
TH4B3021S TM8X060A12MP11 14.5 CF/CM36A 975 29.0 21.2 15.00 12.50 29.2 19.6 8.75 3.86 2.72 26.5 23.7
TH4B3021S TM8X080B12MP11 17.5 CF/CM/CU36B 1000 29.2 21.8 15.25 12.75 29.2 19.6 9.00 3.92 2.74 26.7 24.0
TH4B3021S TM8X080B12MP11 17.5 CF42B 1000 29.4 22.0 15.25 12.50 28.8 19.1 9.00 3.92 2.70 27.0 24.3
TH4B3021S TM8X080C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TM8X080C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TM8X080C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
TH4B3021S TM8X080C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
TH4B3021S TM8X100C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TM8X100C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TM8X100C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
TH4B3021S TM8X100C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
TH4B3021S TM8X100C20MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TM8X100C20MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TM8X100C20MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
TH4B3021S TM8X100C20MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
TH4B3021S TM8X120C20MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TM8X120C20MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TM8X120C20MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
TH4B3021S TM8X120C20MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
TH4B3021S TM8Y060A12MP11 14.5 CF/CM36A 975 29.0 21.2 15.00 12.50 29.2 19.6 8.75 3.86 2.72 26.5 23.7
TH4B3021S TM8Y080B12MP11 17.5 CF/CM/CU36B 1000 29.2 21.8 15.25 12.75 29.2 19.6 9.00 3.92 2.74 26.7 24.0
TH4B3021S TM8Y080B12MP11 17.5 CF42B 1000 29.4 22.0 15.25 12.50 28.8 19.1 9.00 3.92 2.70 27.0 24.3
TH4B3021S TM8Y080C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TM8Y080C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TM8Y080C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
TH4B3021S TM8Y080C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
TH4B3021S TM8Y100C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TM8Y100C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TM8Y100C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
TH4B3021S TM8Y100C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
TH4B3021S TM8Y100C20MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TM8Y100C20MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TM8Y100C20MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
TH4B3021S TM8Y100C20MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
