TH4B3021S TM9Y080B12MP11 17.5 CF/CM/CU36B 900 28.8 20.4 15.25 12.50 29.0 19.5 9.00 3.86 2.74 26.5 23.6
TH4B3021S TM9Y080B12MP11 17.5 CF42B 900 29.6 21.0 15.50 13.00 28.4 19.0 8.75 3.86 2.70 27.4 24.3
TH4B3021S TM9Y080C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.6 15.00 12.50 29.2 19.6 8.75 3.90 2.72 26.7 23.8
TH4B3021S TM9Y080C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.00 12.50 29.2 19.6 8.75 3.90 2.74 26.7 24.0
TH4B3021S TM9Y080C16MP11 21.0 CF/CM/CU42C 1000 29.4 22.0 15.25 12.50 28.8 19.2 8.75 3.90 2.70 27.0 24.3
TH4B3021S TM9Y080C16MP11 21.0 CF/CM/CU42D 1000 29.4 22.0 15.25 12.75 28.8 19.1 9.00 3.92 2.70 27.0 24.3
TH4B3021S TM9Y100C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.6 15.00 12.50 29.2 19.6 8.75 3.90 2.72 26.7 23.8
TH4B3021S TM9Y100C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.00 12.50 29.2 19.6 8.75 3.90 2.74 26.7 24.0
TH4B3021S TM9Y100C16MP11 21.0 CF/CM/CU42C 1000 29.4 22.0 15.25 12.50 28.8 19.2 8.75 3.90 2.70 27.0 24.3
TH4B3021S TM9Y100C16MP11 21.0 CF/CM/CU42D 1000 29.4 22.0 15.25 12.75 28.8 19.1 9.00 3.92 2.70 27.0 24.3
TH4B3021S TM9Y100C20MP11 21.0 CF/CM/CU36C 975 29.2 21.6 15.50 12.75 29.0 19.4 9.00 3.96 2.78 26.7 24.1
TH4B3021S TM9Y100C20MP11 21.0 CF/CM/CU36D 975 29.2 21.6 15.75 13.00 29.0 19.4 9.00 3.98 2.78 26.7 24.1
TH4B3021S TM9Y100C20MP11 21.0 CF/CM/CU42C 975 29.6 22.2 16.00 13.00 28.6 18.9 9.00 4.00 2.76 27.3 24.8
TH4B3021S TM9Y100C20MP11 21.0 CF/CM/CU42D 975 29.6 22.2 16.00 13.00 28.6 18.9 9.00 4.02 2.76 27.3 24.8
TH4B3021S TM9Y120D20MP11 24.5 CF/CM/CU36D 975 29.2 21.6 16.00 13.00 28.8 19.3 9.00 4.00 2.80 26.9 24.1
TH4B3021S TM9Y120D20MP11 24.5 CF/CM/CU42D 975 29.8 22.2 16.00 13.00 28.4 18.9 9.00 4.04 2.78 27.3 24.6
TH4B3021S TMLV060A12MP11 14.5 CF/CM36A 975 28.8 21.2 14.25 12.00 29.4 19.8 8.75 3.80 2.66 26.3 23.7
TH4B3021S TMLV080B12MP11 17.5 CF/CM/CU36B 1025 29.2 21.8 14.75 12.50 29.4 19.7 8.75 3.86 2.70 26.6 23.8
TH4B3021S TMLV080B12MP11 17.5 CF42B 1000 29.4 21.8 15.00 12.50 29.0 19.3 8.75 3.86 2.66 27.0 24.0
TH4B3021S TMLV080C16MP11 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 3.88 2.76 26.4 23.5
TH4B3021S TMLV080C16MP11 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 3.92 2.72 27.3 24.4
TH4B3021S TMLV100C16MP11 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 3.88 2.76 26.4 23.5
TH4B3021S TMLV100C16MP11 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 3.92 2.72 27.3 24.4
TH4B3021S TMLX060A12MP11 14.5 CF/CM36A 975 29.0 21.2 15.00 12.50 29.2 19.6 8.75 3.86 2.72 26.5 23.7
TH4B3021S TMLX080B12MP11 17.5 CF/CM/CU36B 1000 29.2 21.8 15.25 12.75 29.2 19.6 9.00 3.92 2.74 26.7 24.0
TH4B3021S TMLX080B12MP11 17.5 CF42B 1000 29.4 22.0 15.25 12.50 28.8 19.1 9.00 3.92 2.70 27.0 24.3
TH4B3021S TMLX080C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TMLX080C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TMLX080C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
TH4B3021S TMLX080C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
TH4B3021S TMLX100C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TMLX100C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TMLX100C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
TH4B3021S TMLX100C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
TH4B3021S TMLX100C20MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TMLX100C20MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TMLX100C20MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
