Coleman TH4B6021S - Page 16

5005749-CTG-A-0216
16 Johnson Controls Unitary Products
TH4B3021S TMLX100C20MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
TH4B3021S TMLX120C20MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 3.94 2.76 26.7 24.0
TH4B3021S TMLX120C20MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 3.94 2.76 26.8 24.0
TH4B3021S TMLX120C20MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 3.96 2.72 27.2 24.3
TH4B3021S TMLX120C20MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 3.96 2.74 27.2 24.3
TH4B3021S TP9C060B12MP12 17.5 CF/CM/CU36B 950 29.0 21.2 15.00 12.50 29.0 19.6 9.00 3.88 2.72 26.6 24.0
TH4B3021S TP9C060B12MP12 17.5 CF42B 925 29.8 21.4 15.50 13.00 28.6 19.0 9.00 3.90 2.70 27.3 24.3
TH4B3021S TP9C080B12MP12 17.5 CF/CM/CU36B 950 29.0 21.2 15.00 12.50 29.0 19.6 9.00 3.88 2.72 26.6 24.0
TH4B3021S TP9C080B12MP12 17.5 CF42B 925 29.8 21.4 15.50 13.00 28.6 19.0 9.00 3.90 2.70 27.3 24.3
TH4B3021S TP9C080C16MP12 21.0 CF/CM/CU36C 975 29.2 21.6 15.50 13.00 29.0 19.4 9.00 3.96 2.78 26.7 24.1
TH4B3021S TP9C080C16MP12 21.0 CF/CM/CU42C 975 29.6 22.0 15.75 13.00 28.6 19.0 9.00 3.98 2.74 27.3 24.6
TH4B3021S TP9C100C16MP12 21.0 CF/CM/CU36C 975 29.2 21.6 15.50 13.00 29.0 19.4 9.00 3.96 2.78 26.7 24.1
TH4B3021S TP9C100C16MP12 21.0 CF/CM/CU42C 975 29.6 22.0 15.75 13.00 28.6 19.0 9.00 3.98 2.74 27.3 24.6
TH4B3021S TP9C100C20MP12 21.0 CF/CM/CU36C 1075 29.0 22.4 15.00 12.50 29.2 19.6 8.75 3.96 2.74 26.3 23.9
TH4B3021S TP9C120D20MP12 24.5 CF/CM/CU36D 1125 29.8 23.2 16.00 13.00 29.0 19.3 9.25 4.12 2.84 27.0 24.2
TH4B3021S TP9C120D20MP12 24.5 CF/CM/CU42D 1125 29.8 23.2 15.50 13.00 29.0 19.7 9.00 4.04 2.80 27.0 24.1
TH4B3021S TPLC060A12MP12 14.5 CF/CM36A 975 28.8 21.2 14.25 12.00 29.4 19.8 8.75 3.80 2.66 26.3 23.7
TH4B3021S TPLC080B12MP12 17.5 CF/CM/CU36B 1025 29.2 21.8 14.75 12.50 29.4 19.7 8.75 3.86 2.70 26.6 23.8
TH4B3021S TPLC080B12MP12 17.5 CF42B 1000 29.4 21.8 15.00 12.50 29.0 19.3 8.75 3.86 2.66 27.0 24.0
TH4B3021S TPLC080C16MP12 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 3.88 2.76 26.4 23.5
TH4B3021S TPLC080C16MP12 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 3.92 2.72 27.3 24.4
TH4B3021S TPLC100C16MP12 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 3.88 2.76 26.4 23.5
TH4B3021S TPLC100C16MP12 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 3.92 2.72 27.3 24.4
TH4B3021S CP9C060B12MP12 17.5 CF/CM/CU36B 950 29.0 21.2 15.00 12.50 29.0 19.6 9.00 3.88 2.72 26.6 24.0
TH4B3021S CP9C060B12MP12 17.5 CF42B 925 29.8 21.4 15.50 13.00 28.6 19.0 9.00 3.90 2.70 27.3 24.3
TH4B3021S CP9C080B12MP12 17.5 CF/CM/CU36B 950 29.0 21.2 15.00 12.50 29.0 19.6 9.00 3.88 2.72 26.6 24.0
TH4B3021S CP9C080B12MP12 17.5 CF42B 925 29.8 21.4 15.50 13.00 28.6 19.0 9.00 3.90 2.70 27.3 24.3
TH4B3021S CP9C080C16MP12 21.0 CF/CM/CU36C 975 29.2 21.6 15.50 13.00 29.0 19.4 9.00 3.96 2.78 26.7 24.1
TH4B3021S CP9C080C16MP12 21.0 CF/CM/CU42C 975 29.6 22.0 15.75 13.00 28.6 19.0 9.00 3.98 2.74 27.3 24.6
TH4B3021S CP9C100C16MP12 21.0 CF/CM/CU36C 975 29.2 21.6 15.50 13.00 29.0 19.4 9.00 3.96 2.78 26.7 24.1
TH4B3021S CP9C100C16MP12 21.0 CF/CM/CU42C 975 29.6 22.0 15.75 13.00 28.6 19.0 9.00 3.98 2.74 27.3 24.6
TH4B3021S CP9C100C20MP12 21.0 CF/CM/CU36C 1075 29.0 22.4 15.00 12.50 29.2 19.6 8.75 3.96 2.74 26.3 23.9
TH4B3021S CP9C120D20MP12 24.5 CF/CM/CU36D 1125 29.8 23.2 16.00 13.00 29.0 19.3 9.25 4.12 2.84 27.0 24.2
TH4B3021S CP9C120D20MP12 24.5 CF/CM/CU42D 1125 29.8 23.2 15.50 13.00 29.0 19.7 9.00 4.04 2.80 27.0 24.1
TH4B3021S CPLC060A12MP12 14.5 CF/CM36A 975 28.8 21.2 14.25 12.00 29.4 19.8 8.75 3.80 2.66 26.3 23.7
TH4B3021S CPLC080B12MP12 17.5 CF/CM/CU36B 1025 29.2 21.8 14.75 12.50 29.4 19.7 8.75 3.86 2.70 26.6 23.8
TH4B3021S CPLC080B12MP12 17.5 CF42B 1000 29.4 21.8 15.00 12.50 29.0 19.3 8.75 3.86 2.66 27.0 24.0
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
