TH4B3021S CPLC080C16MP12 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 3.88 2.76 26.4 23.5
TH4B3021S CPLC080C16MP12 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 3.92 2.72 27.3 24.4
TH4B3021S CPLC100C16MP12 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 3.88 2.76 26.4 23.5
TH4B3021S CPLC100C16MP12 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 3.92 2.72 27.3 24.4
TH4B3521S TM8V080B12MP11 17.5 CF42B 1000 34.4 24.0 14.00 11.75 33.6 21.4 8.50 3.50 2.40 34.2 28.7
TH4B3521S TM8V080C16MP11 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 12.00 33.6 21.6 8.50 3.54 2.44 34.0 28.2
TH4B3521S TM8V080C16MP11 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.68 2.48 34.6 29.7
TH4B3521S TM8V100C16MP11 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 12.00 33.6 21.6 8.50 3.54 2.44 34.0 28.2
TH4B3521S TM8V100C16MP11 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.68 2.48 34.6 29.7
TH4B3521S TM8V100C20MP11 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 11.75 33.6 21.8 8.50 3.50 2.42 34.0 28.2
TH4B3521S TM8V100C20MP11 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.66 2.46 34.6 29.7
TH4B3521S TM8V120C20MP11 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 11.75 33.6 21.8 8.50 3.50 2.42 34.0 28.2
TH4B3521S TM8V120C20MP11 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.66 2.46 34.6 29.7
TH4B3521S TM8X080B12MP11 17.5 CF42B 1175 35.0 25.8 14.00 11.75 34.0 21.6 8.50 3.60 2.42 34.1 28.5
TH4B3521S TM8X080C16MP11 21.0 CF/CM/CU36C 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.50 3.56 2.44 33.9 27.5
TH4B3521S TM8X080C16MP11 21.0 CF/CM/CU36D 1075 34.8 24.6 14.50 12.00 33.4 21.6 8.50 3.54 2.46 34.3 28.5
TH4B3521S TM8X080C16MP11 21.0 CF/CM/CU42C 1225 35.6 26.8 14.00 12.00 33.8 21.4 8.75 3.70 2.48 34.5 29.2
TH4B3521S TM8X080C16MP11 21.0 CF/CM/CU42D 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TM8X100C16MP11 21.0 CF/CM/CU36C 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.50 3.56 2.44 33.9 27.5
TH4B3521S TM8X100C16MP11 21.0 CF/CM/CU36D 1075 34.8 24.6 14.50 12.00 33.4 21.6 8.50 3.54 2.46 34.3 28.5
TH4B3521S TM8X100C16MP11 21.0 CF/CM/CU42C 1225 35.6 26.8 14.00 12.00 33.8 21.4 8.75 3.70 2.48 34.5 29.2
TH4B3521S TM8X100C16MP11 21.0 CF/CM/CU42D 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TM8X100C20MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.25 12.00 33.4 21.6 8.50 3.54 2.44 34.1 28.2
TH4B3521S TM8X100C20MP11 21.0 CF/CM/CU36D 1100 34.8 24.8 14.25 12.25 33.4 21.6 8.50 3.56 2.46 34.2 28.4
TH4B3521S TM8X100C20MP11 21.0 CF/CM/CU42C 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TM8X100C20MP11 21.0 CF/CM/CU42D 1100 35.4 26.0 14.75 12.50 33.6 21.2 8.75 3.74 2.52 34.8 29.7
TH4B3521S TM8X120C20MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.25 12.00 33.4 21.6 8.50 3.54 2.44 34.1 28.2
TH4B3521S TM8X120C20MP11 21.0 CF/CM/CU36D 1100 34.8 24.8 14.25 12.25 33.4 21.6 8.50 3.56 2.46 34.2 28.4
TH4B3521S TM8X120C20MP11 21.0 CF/CM/CU42C 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TM8X120C20MP11 21.0 CF/CM/CU42D 1100 35.4 26.0 14.75 12.50 33.6 21.2 8.75 3.74 2.52 34.8 29.7
TH4B3521S TM8Y080B12MP11 17.5 CF42B 1175 35.0 25.8 14.00 11.75 34.0 21.6 8.50 3.60 2.42 34.1 28.5
TH4B3521S TM8Y080C16MP11 21.0 CF/CM/CU36C 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.50 3.56 2.44 33.9 27.5
TH4B3521S TM8Y080C16MP11 21.0 CF/CM/CU36D 1075 34.8 24.6 14.50 12.00 33.4 21.6 8.50 3.54 2.46 34.3 28.5
TH4B3521S TM8Y080C16MP11 21.0 CF/CM/CU42C 1225 35.6 26.8 14.00 12.00 33.8 21.4 8.75 3.70 2.48 34.5 29.2
TH4B3521S TM8Y080C16MP11 21.0 CF/CM/CU42D 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TM8Y100C16MP11 21.0 CF/CM/CU36C 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.50 3.56 2.44 33.9 27.5
TH4B3521S TM8Y100C16MP11 21.0 CF/CM/CU36D 1075 34.8 24.6 14.50 12.00 33.4 21.6 8.50 3.54 2.46 34.3 28.5
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
