Coleman TH4B6021S - Page 18

5005749-CTG-A-0216
18 Johnson Controls Unitary Products
TH4B3521S TM8Y100C16MP11 21.0 CF/CM/CU42C 1225 35.6 26.8 14.00 12.00 33.8 21.4 8.75 3.70 2.48 34.5 29.2
TH4B3521S TM8Y100C16MP11 21.0 CF/CM/CU42D 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TM8Y100C20MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.25 12.00 33.4 21.6 8.50 3.54 2.44 34.1 28.2
TH4B3521S TM8Y100C20MP11 21.0 CF/CM/CU36D 1100 34.8 24.8 14.25 12.25 33.4 21.6 8.50 3.56 2.46 34.2 28.4
TH4B3521S TM8Y100C20MP11 21.0 CF/CM/CU42C 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TM8Y100C20MP11 21.0 CF/CM/CU42D 1100 35.4 26.0 14.75 12.50 33.6 21.2 8.75 3.74 2.52 34.8 29.7
TH4B3521S TM8Y120C20MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.25 12.00 33.4 21.6 8.50 3.54 2.44 34.1 28.2
TH4B3521S TM8Y120C20MP11 21.0 CF/CM/CU36D 1100 34.8 24.8 14.25 12.25 33.4 21.6 8.50 3.56 2.46 34.2 28.4
TH4B3521S TM8Y120C20MP11 21.0 CF/CM/CU42C 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TM8Y120C20MP11 21.0 CF/CM/CU42D 1100 35.4 26.0 14.75 12.50 33.6 21.2 8.75 3.74 2.52 34.8 29.7
TH4B3521S TM9E080C16MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.00 12.00 33.6 21.6 8.50 3.50 2.42 34.1 28.2
TH4B3521S TM9E080C16MP11 21.0 CF/CM/CU36D 1075 34.6 24.4 14.25 12.00 33.6 21.6 8.50 3.52 2.44 34.1 28.2
TH4B3521S TM9E080C16MP11 21.0 CF/CM/CU42C 1225 35.4 26.6 14.00 12.00 34.0 21.6 8.50 3.66 2.46 34.3 29.0
TH4B3521S TM9E080C16MP11 21.0 CF/CM/CU42D 1075 35.0 25.2 14.25 12.25 33.6 21.2 8.75 3.64 2.46 34.5 29.1
TH4B3521S TM9E100C16MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.00 12.00 33.6 21.6 8.50 3.50 2.42 34.1 28.2
TH4B3521S TM9E100C16MP11 21.0 CF/CM/CU36D 1075 34.6 24.4 14.25 12.00 33.6 21.6 8.50 3.52 2.44 34.1 28.2
TH4B3521S TM9E100C16MP11 21.0 CF/CM/CU42C 1225 35.4 26.6 14.00 12.00 34.0 21.6 8.50 3.66 2.46 34.3 29.0
TH4B3521S TM9E100C16MP11 21.0 CF/CM/CU42D 1075 35.0 25.2 14.25 12.25 33.6 21.2 8.75 3.64 2.46 34.5 29.1
TH4B3521S TM9E100C20MP11 21.0 CF/CM/CU36C 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.25 3.54 2.42 33.9 27.5
TH4B3521S TM9E100C20MP11 21.0 CF/CM/CU36D 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.25 3.54 2.42 33.9 27.5
TH4B3521S TM9E100C20MP11 21.0 CF/CM/CU42C 1225 35.6 26.8 14.00 12.00 34.0 21.6 8.75 3.68 2.46 34.5 29.0
TH4B3521S TM9E100C20MP11 21.0 CF/CM/CU42D 1200 35.0 25.8 14.00 11.75 33.8 21.6 8.50 3.62 2.44 34.0 28.2
TH4B3521S TM9E120D20MP11 24.5 CF/CM/CU36D 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.50 3.56 2.44 33.9 27.5
TH4B3521S TM9E120D20MP11 24.5 CF/CM/CU42D 1200 35.2 25.8 14.25 12.00 33.8 21.4 8.50 3.64 2.46 34.2 28.2
TH4B3521S TM9V060B12MP11 17.5 CF42B 1175 35.0 25.8 14.00 11.75 34.0 21.6 8.50 3.60 2.42 34.1 28.5
TH4B3521S TM9V080B12MP11 17.5 CF42B 1175 35.0 25.8 14.00 11.75 34.0 21.6 8.50 3.60 2.42 34.1 28.5
TH4B3521S TM9V080C16MP11 21.0 CF/CM/CU42C 1275 35.4 27.0 14.00 11.75 34.2 21.6 8.50 3.68 2.46 34.1 28.8
TH4B3521S TM9V100C16MP11 21.0 CF/CM/CU42C 1275 35.4 27.0 14.00 11.75 34.2 21.6 8.50 3.68 2.46 34.1 28.8
TH4B3521S TM9V100C20MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.00 11.75 33.6 21.6 8.50 3.48 2.42 34.1 28.2
TH4B3521S TM9V100C20MP11 21.0 CF/CM/CU42C 1275 35.4 27.0 14.00 11.75 34.2 21.8 8.50 3.66 2.44 34.1 28.8
TH4B3521S TM9V120D20MP11 24.5 CF/CM/CU42D 1125 35.2 26.0 14.50 12.00 33.6 21.4 8.75 3.68 2.48 34.5 29.4
TH4B3521S TM9Y080C16MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.00 12.00 33.6 21.6 8.50 3.50 2.42 34.1 28.2
TH4B3521S TM9Y080C16MP11 21.0 CF/CM/CU36D 1075 34.6 24.4 14.25 12.00 33.6 21.6 8.50 3.52 2.44 34.1 28.2
TH4B3521S TM9Y080C16MP11 21.0 CF/CM/CU42C 1225 35.4 26.6 14.00 12.00 34.0 21.6 8.50 3.66 2.46 34.3 29.0
TH4B3521S TM9Y080C16MP11 21.0 CF/CM/CU42D 1075 35.0 25.2 14.25 12.25 33.6 21.2 8.75 3.64 2.46 34.5 29.1
TH4B3521S TM9Y100C16MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.00 12.00 33.6 21.6 8.50 3.50 2.42 34.1 28.2
TH4B3521S TM9Y100C16MP11 21.0 CF/CM/CU36D 1075 34.6 24.4 14.25 12.00 33.6 21.6 8.50 3.52 2.44 34.1 28.2
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
