Coleman TH4B6021S - Page 19

5005749-CTG-A-0216
Johnson Controls Unitary Products 19
TH4B3521S TM9Y100C16MP11 21.0 CF/CM/CU42C 1225 35.4 26.6 14.00 12.00 34.0 21.6 8.50 3.66 2.46 34.3 29.0
TH4B3521S TM9Y100C16MP11 21.0 CF/CM/CU42D 1075 35.0 25.2 14.25 12.25 33.6 21.2 8.75 3.64 2.46 34.5 29.1
TH4B3521S TM9Y100C20MP11 21.0 CF/CM/CU36C 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.25 3.54 2.42 33.9 27.5
TH4B3521S TM9Y100C20MP11 21.0 CF/CM/CU36D 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.25 3.54 2.42 33.9 27.5
TH4B3521S TM9Y100C20MP11 21.0 CF/CM/CU42C 1225 35.6 26.8 14.00 12.00 34.0 21.6 8.75 3.68 2.46 34.5 29.0
TH4B3521S TM9Y100C20MP11 21.0 CF/CM/CU42D 1200 35.0 25.8 14.00 11.75 33.8 21.6 8.50 3.62 2.44 34.0 28.2
TH4B3521S TM9Y120D20MP11 24.5 CF/CM/CU36D 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.50 3.56 2.44 33.9 27.5
TH4B3521S TM9Y120D20MP11 24.5 CF/CM/CU42D 1200 35.2 25.8 14.25 12.00 33.8 21.4 8.50 3.64 2.46 34.2 28.2
TH4B3521S TMLV080B12MP11 17.5 CF42B 1000 34.4 24.0 14.00 11.75 33.6 21.4 8.50 3.50 2.40 34.2 28.7
TH4B3521S TMLV080C16MP11 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 12.00 33.6 21.6 8.50 3.54 2.44 34.0 28.2
TH4B3521S TMLV080C16MP11 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.68 2.48 34.6 29.7
TH4B3521S TMLV100C16MP11 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 12.00 33.6 21.6 8.50 3.54 2.44 34.0 28.2
TH4B3521S TMLV100C16MP11 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.68 2.48 34.6 29.7
TH4B3521S TMLV100C20MP11 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 11.75 33.6 21.8 8.50 3.50 2.42 34.0 28.2
TH4B3521S TMLV100C20MP11 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.66 2.46 34.6 29.7
TH4B3521S TMLV120C20MP11 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 11.75 33.6 21.8 8.50 3.50 2.42 34.0 28.2
TH4B3521S TMLV120C20MP11 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.66 2.46 34.6 29.7
TH4B3521S TMLX080B12MP11 17.5 CF42B 1175 35.0 25.8 14.00 11.75 34.0 21.6 8.50 3.60 2.42 34.1 28.5
TH4B3521S TMLX080C16MP11 21.0 CF/CM/CU36C 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.50 3.56 2.44 33.9 27.5
TH4B3521S TMLX080C16MP11 21.0 CF/CM/CU36D 1075 34.8 24.6 14.50 12.00 33.4 21.6 8.50 3.54 2.46 34.3 28.5
TH4B3521S TMLX080C16MP11 21.0 CF/CM/CU42C 1225 35.6 26.8 14.00 12.00 33.8 21.4 8.75 3.70 2.48 34.5 29.2
TH4B3521S TMLX080C16MP11 21.0 CF/CM/CU42D 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TMLX100C16MP11 21.0 CF/CM/CU36C 1225 35.0 25.4 14.00 11.75 33.8 21.8 8.50 3.56 2.44 33.9 27.5
TH4B3521S TMLX100C16MP11 21.0 CF/CM/CU36D 1075 34.8 24.6 14.50 12.00 33.4 21.6 8.50 3.54 2.46 34.3 28.5
TH4B3521S TMLX100C16MP11 21.0 CF/CM/CU42C 1225 35.6 26.8 14.00 12.00 33.8 21.4 8.75 3.70 2.48 34.5 29.2
TH4B3521S TMLX100C16MP11 21.0 CF/CM/CU42D 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TMLX100C20MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.25 12.00 33.4 21.6 8.50 3.54 2.44 34.1 28.2
TH4B3521S TMLX100C20MP11 21.0 CF/CM/CU36D 1100 34.8 24.8 14.25 12.25 33.4 21.6 8.50 3.56 2.46 34.2 28.4
TH4B3521S TMLX100C20MP11 21.0 CF/CM/CU42C 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TMLX100C20MP11 21.0 CF/CM/CU42D 1100 35.4 26.0 14.75 12.50 33.6 21.2 8.75 3.74 2.52 34.8 29.7
TH4B3521S TMLX120C20MP11 21.0 CF/CM/CU36C 1075 34.6 24.4 14.25 12.00 33.4 21.6 8.50 3.54 2.44 34.1 28.2
TH4B3521S TMLX120C20MP11 21.0 CF/CM/CU36D 1100 34.8 24.8 14.25 12.25 33.4 21.6 8.50 3.56 2.46 34.2 28.4
TH4B3521S TMLX120C20MP11 21.0 CF/CM/CU42C 1075 35.2 25.2 14.50 12.25 33.4 21.2 8.75 3.66 2.48 34.7 29.2
TH4B3521S TMLX120C20MP11 21.0 CF/CM/CU42D 1100 35.4 26.0 14.75 12.50 33.6 21.2 8.75 3.74 2.52 34.8 29.7
TH4B3521S TP9C060B12MP12 17.5 CF42B 1175 35.0 25.8 14.00 11.75 34.0 21.6 8.50 3.60 2.42 34.1 28.5
TH4B3521S TP9C080B12MP12 17.5 CF42B 1175 35.0 25.8 14.00 11.75 34.0 21.6 8.50 3.60 2.42 34.1 28.5
TH4B3521S TP9C080C16MP12 21.0 CF/CM/CU42C 1275 35.4 27.0 14.00 11.75 34.2 21.6 8.50 3.68 2.46 34.1 28.8
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
