Coleman TH4B6021S - Page 20

5005749-CTG-A-0216
20 Johnson Controls Unitary Products
TH4B3521S TP9C100C16MP12 21.0 CF/CM/CU42C 1275 35.4 27.0 14.00 11.75 34.2 21.6 8.50 3.68 2.46 34.1 28.8
TH4B3521S TP9C100C20MP12 21.0 CF/CM/CU36C 1075 34.6 24.4 14.00 11.75 33.6 21.6 8.50 3.48 2.42 34.1 28.2
TH4B3521S TP9C100C20MP12 21.0 CF/CM/CU42C 1275 35.4 27.0 14.00 11.75 34.2 21.8 8.50 3.66 2.44 34.1 28.8
TH4B3521S TP9C120D20MP12 24.5 CF/CM/CU42D 1125 35.2 26.0 14.50 12.00 33.6 21.4 8.75 3.68 2.48 34.5 29.4
TH4B3521S TPLC080B12MP12 17.5 CF42B 1000 34.4 24.0 14.00 11.75 33.6 21.4 8.50 3.50 2.40 34.2 28.7
TH4B3521S TPLC080C16MP12 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 12.00 33.6 21.6 8.50 3.54 2.44 34.0 28.2
TH4B3521S TPLC080C16MP12 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.68 2.48 34.6 29.7
TH4B3521S TPLC100C16MP12 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 12.00 33.6 21.6 8.50 3.54 2.44 34.0 28.2
TH4B3521S TPLC100C16MP12 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.68 2.48 34.6 29.7
TH4B3521S TPLC100C20MP12 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 11.75 33.6 21.8 8.50 3.50 2.42 34.0 28.2
TH4B3521S TPLC100C20MP12 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.66 2.46 34.6 29.7
TH4B3521S TPLC120C20MP12 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 11.75 33.6 21.8 8.50 3.50 2.42 34.0 28.2
TH4B3521S TPLC120C20MP12 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.66 2.46 34.6 29.7
TH4B3521S CP9C060B12MP12 17.5 CF42B 1175 35.0 25.8 14.00 11.75 34.0 21.6 8.50 3.60 2.42 34.1 28.5
TH4B3521S CP9C080B12MP12 17.5 CF42B 1175 35.0 25.8 14.00 11.75 34.0 21.6 8.50 3.60 2.42 34.1 28.5
TH4B3521S CP9C080C16MP12 21.0 CF/CM/CU42C 1275 35.4 27.0 14.00 11.75 34.2 21.6 8.50 3.68 2.46 34.1 28.8
TH4B3521S CP9C100C16MP12 21.0 CF/CM/CU42C 1275 35.4 27.0 14.00 11.75 34.2 21.6 8.50 3.68 2.46 34.1 28.8
TH4B3521S CP9C100C20MP12 21.0 CF/CM/CU36C 1075 34.6 24.4 14.00 11.75 33.6 21.6 8.50 3.48 2.42 34.1 28.2
TH4B3521S CP9C100C20MP12 21.0 CF/CM/CU42C 1275 35.4 27.0 14.00 11.75 34.2 21.8 8.50 3.66 2.44 34.1 28.8
TH4B3521S CP9C120D20MP12 24.5 CF/CM/CU42D 1125 35.2 26.0 14.50 12.00 33.6 21.4 8.75 3.68 2.48 34.5 29.4
TH4B3521S CPLC080B12MP12 17.5 CF42B 1000 34.4 24.0 14.00 11.75 33.6 21.4 8.50 3.50 2.40 34.2 28.7
TH4B3521S CPLC080C16MP12 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 12.00 33.6 21.6 8.50 3.54 2.44 34.0 28.2
TH4B3521S CPLC080C16MP12 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.68 2.48 34.6 29.7
TH4B3521S CPLC100C16MP12 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 12.00 33.6 21.6 8.50 3.54 2.44 34.0 28.2
TH4B3521S CPLC100C16MP12 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.68 2.48 34.6 29.7
TH4B3521S CPLC100C20MP12 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 11.75 33.6 21.8 8.50 3.50 2.42 34.0 28.2
TH4B3521S CPLC100C20MP12 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.66 2.46 34.6 29.7
TH4B3521S CPLC120C20MP12 21.0 CF/CM/CU36C 1100 34.6 24.6 14.00 11.75 33.6 21.8 8.50 3.50 2.42 34.0 28.2
TH4B3521S CPLC120C20MP12 21.0 CF/CM/CU42C 1100 35.2 26.0 14.25 12.00 33.8 21.4 8.75 3.66 2.46 34.6 29.7
TH4B3621H TM8V080C16MP11 21.0 CF/CM/CU48C 1150 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.60 34.6 27.1
TH4B3621H TM8V100C16MP11 21.0 CF/CM/CU48C 1150 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.60 34.6 27.1
TH4B3621H TM8V100C20MP11 21.0 CF/CM/CU48D 1225 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.62 2.58 34.1 26.2
TH4B3621H TM8V120C20MP11 21.0 CF/CM/CU48D 1225 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.62 2.58 34.1 26.2
TH4B3621H TM8X080C16MP11 21.0 CF/CM/CU48C 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
TH4B3621H TM8X080C16MP11 21.0 CF/CM/CU48D 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
TH4B3621H TM8X100C16MP11 21.0 CF/CM/CU48C 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
TH4B3621H TM8X100C16MP11 21.0 CF/CM/CU48D 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
