Coleman TH4B6021S - Page 21

5005749-CTG-A-0216
Johnson Controls Unitary Products 21
TH4B3621H TM8X100C20MP11 21.0 CF/CM/CU48C 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM8X100C20MP11 21.0 CF/CM/CU48D 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM8X120C20MP11 21.0 CF/CM/CU48C 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM8X120C20MP11 21.0 CF/CM/CU48D 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM8Y080C16MP11 21.0 CF/CM/CU48C 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
TH4B3621H TM8Y080C16MP11 21.0 CF/CM/CU48D 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
TH4B3621H TM8Y100C16MP11 21.0 CF/CM/CU48C 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
TH4B3621H TM8Y100C16MP11 21.0 CF/CM/CU48D 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
TH4B3621H TM8Y100C20MP11 21.0 CF/CM/CU48C 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM8Y100C20MP11 21.0 CF/CM/CU48D 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM8Y120C20MP11 21.0 CF/CM/CU48C 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM8Y120C20MP11 21.0 CF/CM/CU48D 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM9E080C16MP11 21.0 CF/CM/CU48C 1175 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.58 2.56 34.3 26.6
TH4B3621H TM9E080C16MP11 21.0 CF/CM/CU48D 1175 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.58 2.56 34.3 26.6
TH4B3621H TM9E100C16MP11 21.0 CF/CM/CU48C 1175 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.58 2.56 34.3 26.6
TH4B3621H TM9E100C16MP11 21.0 CF/CM/CU48D 1175 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.58 2.56 34.3 26.6
TH4B3621H TM9E100C20MP11 21.0 CF/CM/CU48C 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM9E100C20MP11 21.0 CF/CM/CU48D 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM9E120D20MP11 24.5 CF/CM/CU48D 1175 34.2 24.2 15.00 12.50 33.6 19.5 8.50 3.62 2.60 34.5 26.8
TH4B3621H TM9V080C16MP11 21.0 CF/CM/CU48D 1150 34.2 24.2 15.25 12.50 33.4 19.5 8.50 3.66 2.62 34.6 27.1
TH4B3621H TM9V100C16MP11 21.0 CF/CM/CU48D 1150 34.2 24.2 15.25 12.50 33.4 19.5 8.50 3.66 2.62 34.6 27.1
TH4B3621H TM9V100C20MP11 21.0 CF/CM/CU48C 1200 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.60 2.56 34.2 26.3
TH4B3621H TM9V100C20MP11 21.0 CF/CM/CU48D 1250 34.4 25.2 15.00 12.50 34.0 19.8 8.50 3.66 2.58 34.4 27.0
TH4B3621H TM9V120D20MP11 24.5 CF/CM/CU48D 1250 34.4 25.2 15.00 12.50 33.8 19.7 8.50 3.68 2.60 34.4 27.0
TH4B3621H TM9Y080C16MP11 21.0 CF/CM/CU48C 1175 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.58 2.56 34.3 26.6
TH4B3621H TM9Y080C16MP11 21.0 CF/CM/CU48D 1175 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.58 2.56 34.3 26.6
TH4B3621H TM9Y100C16MP11 21.0 CF/CM/CU48C 1175 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.58 2.56 34.3 26.6
TH4B3621H TM9Y100C16MP11 21.0 CF/CM/CU48D 1175 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.58 2.56 34.3 26.6
TH4B3621H TM9Y100C20MP11 21.0 CF/CM/CU48C 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM9Y100C20MP11 21.0 CF/CM/CU48D 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TM9Y120D20MP11 24.5 CF/CM/CU48D 1175 34.2 24.2 15.00 12.50 33.6 19.5 8.50 3.62 2.60 34.5 26.8
TH4B3621H TMLV080C16MP11 21.0 CF/CM/CU48C 1150 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.60 34.6 27.1
TH4B3621H TMLV100C16MP11 21.0 CF/CM/CU48C 1150 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.60 34.6 27.1
TH4B3621H TMLV100C20MP11 21.0 CF/CM/CU48D 1225 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.62 2.58 34.1 26.2
TH4B3621H TMLV120C20MP11 21.0 CF/CM/CU48D 1225 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.62 2.58 34.1 26.2
TH4B3621H TMLX080C16MP11 21.0 CF/CM/CU48C 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
TH4B3621H TMLX080C16MP11 21.0 CF/CM/CU48D 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
