Coleman TH4B6021S - Page 22

5005749-CTG-A-0216
22 Johnson Controls Unitary Products
TH4B3621H TMLX100C16MP11 21.0 CF/CM/CU48C 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
TH4B3621H TMLX100C16MP11 21.0 CF/CM/CU48D 1175 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.58 34.5 26.8
TH4B3621H TMLX100C20MP11 21.0 CF/CM/CU48C 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TMLX100C20MP11 21.0 CF/CM/CU48D 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TMLX120C20MP11 21.0 CF/CM/CU48C 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TMLX120C20MP11 21.0 CF/CM/CU48D 1175 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.60 2.58 34.3 26.8
TH4B3621H TP9C080C16MP12 21.0 CF/CM/CU48D 1150 34.2 24.2 15.25 12.50 33.4 19.5 8.50 3.66 2.62 34.6 27.1
TH4B3621H TP9C100C16MP12 21.0 CF/CM/CU48D 1150 34.2 24.2 15.25 12.50 33.4 19.5 8.50 3.66 2.62 34.6 27.1
TH4B3621H TP9C100C20MP12 21.0 CF/CM/CU48C 1200 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.60 2.56 34.2 26.3
TH4B3621H TP9C100C20MP12 21.0 CF/CM/CU48D 1250 34.4 25.2 15.00 12.50 34.0 19.8 8.50 3.66 2.58 34.4 27.0
TH4B3621H TP9C120D20MP12 24.5 CF/CM/CU48D 1250 34.4 25.2 15.00 12.50 33.8 19.7 8.50 3.68 2.60 34.4 27.0
TH4B3621H TPLC080C16MP12 21.0 CF/CM/CU48C 1150 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.60 34.6 27.1
TH4B3621H TPLC100C16MP12 21.0 CF/CM/CU48C 1150 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.60 34.6 27.1
TH4B3621H TPLC100C20MP12 21.0 CF/CM/CU48D 1225 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.62 2.58 34.1 26.2
TH4B3621H TPLC120C20MP12 21.0 CF/CM/CU48D 1225 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.62 2.58 34.1 26.2
TH4B3621H CP9C080C16MP12 21.0 CF/CM/CU48D 1150 34.2 24.2 15.25 12.50 33.4 19.5 8.50 3.66 2.62 34.6 27.1
TH4B3621H CP9C100C16MP12 21.0 CF/CM/CU48D 1150 34.2 24.2 15.25 12.50 33.4 19.5 8.50 3.66 2.62 34.6 27.1
TH4B3621H CP9C100C20MP12 21.0 CF/CM/CU48C 1200 34.0 24.0 14.75 12.25 33.6 19.7 8.50 3.60 2.56 34.2 26.3
TH4B3621H CP9C100C20MP12 21.0 CF/CM/CU48D 1250 34.4 25.2 15.00 12.50 34.0 19.8 8.50 3.66 2.58 34.4 27.0
TH4B3621H CP9C120D20MP12 24.5 CF/CM/CU48D 1250 34.4 25.2 15.00 12.50 33.8 19.7 8.50 3.68 2.60 34.4 27.0
TH4B3621H CPLC080C16MP12 21.0 CF/CM/CU48C 1150 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.60 34.6 27.1
TH4B3621H CPLC100C16MP12 21.0 CF/CM/CU48C 1150 34.2 24.2 15.00 12.50 33.6 19.6 8.50 3.62 2.60 34.6 27.1
TH4B3621H CPLC100C20MP12 21.0 CF/CM/CU48D 1225 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.62 2.58 34.1 26.2
TH4B3621H CPLC120C20MP12 21.0 CF/CM/CU48D 1225 34.0 24.2 14.75 12.25 33.6 19.6 8.50 3.62 2.58 34.1 26.2
TH4B4221H TM8V080C16MP11 21.0 CF/CM/CU48D 1300 42.0 28.2 14.25 12.25 40.5 24.6 8.50 3.60 2.66 37.0 28.2
TH4B4221H TM8V080C16MP11 21.0 CF/CM/CU60D 1325 42.0 28.0 14.50 12.25 40.5 24.6 8.50 3.60 2.64 36.7 27.8
TH4B4221H TM8V100C16MP11 21.0 CF/CM/CU48D 1300 42.0 28.2 14.25 12.25 40.5 24.6 8.50 3.60 2.66 37.0 28.2
TH4B4221H TM8V100C16MP11 21.0 CF/CM/CU60D 1325 42.0 28.0 14.50 12.25 40.5 24.6 8.50 3.60 2.64 36.7 27.8
TH4B4221H TM8V100C20MP11 21.0 CF/CM/CU48C 1250 42.0 28.4 14.50 12.25 40.5 24.4 8.50 3.62 2.68 37.4 27.3
TH4B4221H TM8V100C20MP11 21.0 CF/CM/CU48D 1225 42.0 28.4 14.50 12.50 40.5 24.4 8.50 3.64 2.68 37.6 29.2
TH4B4221H TM8V100C20MP11 21.0 CF/CM/CU60C 1225 42.0 28.0 14.50 12.50 40.5 24.4 8.50 3.62 2.66 37.6 28.9
TH4B4221H TM8V100C20MP11 21.0 CF/CM/CU60D 1225 42.0 28.0 14.50 12.50 40.5 24.4 8.50 3.62 2.66 37.6 28.9
TH4B4221H TM8V120C20MP11 21.0 CF/CM/CU48C 1250 42.0 28.4 14.50 12.25 40.5 24.4 8.50 3.62 2.68 37.4 28.9
TH4B4221H TM8V120C20MP11 21.0 CF/CM/CU48D 1225 42.0 28.4 14.50 12.50 40.5 24.4 8.50 3.64 2.68 37.6 29.2
TH4B4221H TM8V120C20MP11 21.0 CF/CM/CU60C 1225 42.0 28.0 14.50 12.50 40.5 24.4 8.50 3.62 2.66 37.6 28.9
TH4B4221H TM8V120C20MP11 21.0 CF/CM/CU60D 1225 42.0 28.0 14.50 12.50 40.5 24.4 8.50 3.62 2.66 37.6 28.9
TH4B4221H TM8X080C16MP11 21.0 CF/CM/CU48C 1200 42.0 27.8 14.50 12.50 40.5 24.2 8.50 3.60 2.68 37.8 27.8
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
