Coleman TH4B6021S - Page 23

5005749-CTG-A-0216
Johnson Controls Unitary Products 23
TH4B4221H TM8X080C16MP11 21.0 CF/CM/CU48D 1200 42.0 27.8 14.50 12.50 40.5 24.4 8.50 3.60 2.68 37.8 28.8
TH4B4221H TM8X080C16MP11 21.0 CF/CM/CU60C 1200 42.0 27.8 14.75 12.50 40.0 24.2 8.50 3.58 2.66 37.8 28.9
TH4B4221H TM8X080C16MP11 21.0 CF/CM/CU60D 1225 42.0 28.2 14.75 12.75 40.5 24.2 8.50 3.64 2.68 37.6 29.1
TH4B4221H TM8X100C16MP11 21.0 CF/CM/CU48C 1200 42.0 27.8 14.50 12.50 40.5 24.2 8.50 3.60 2.68 37.8 27.8
TH4B4221H TM8X100C16MP11 21.0 CF/CM/CU48D 1200 42.0 27.8 14.50 12.50 40.5 24.4 8.50 3.60 2.68 37.6 27.5
TH4B4221H TM8X100C16MP11 21.0 CF/CM/CU60C 1200 42.0 27.8 14.75 12.50 40.0 24.2 8.50 3.58 2.66 37.8 28.8
TH4B4221H TM8X100C16MP11 21.0 CF/CM/CU60D 1225 42.0 28.2 14.75 12.75 40.5 24.2 8.50 3.64 2.68 37.8 28.8
TH4B4221H TM8X100C20MP11 21.0 CF/CM/CU48C 1275 42.0 28.4 14.50 12.50 40.5 24.4 8.50 3.64 2.70 37.8 28.9
TH4B4221H TM8X100C20MP11 21.0 CF/CM/CU48D 1275 42.0 28.4 14.75 12.50 40.5 24.4 8.75 3.66 2.70 37.6 29.1
TH4B4221H TM8X100C20MP11 21.0 CF/CM/CU60C 1275 42.0 28.2 14.75 12.75 40.5 24.4 8.50 3.64 2.68 37.8 27.8
TH4B4221H TM8X100C20MP11 21.0 CF/CM/CU60D 1275 42.0 28.2 14.75 12.75 40.5 24.2 8.75 3.64 2.68 37.6 27.5
TH4B4221H TM8X120C20MP11 21.0 CF/CM/CU48C 1275 42.0 28.4 14.50 12.50 40.5 24.4 8.50 3.64 2.70 37.2 28.7
TH4B4221H TM8X120C20MP11 21.0 CF/CM/CU48D 1275 42.0 28.4 14.75 12.50 40.5 24.4 8.75 3.66 2.70 37.2 28.7
TH4B4221H TM8X120C20MP11 21.0 CF/CM/CU60C 1275 42.0 28.2 14.75 12.75 40.5 24.4 8.50 3.64 2.68 37.2 28.5
TH4B4221H TM8X120C20MP11 21.0 CF/CM/CU60D 1275 42.0 28.2 14.75 12.75 40.5 24.2 8.75 3.64 2.68 37.2 28.5
TH4B4221H TM8Y080C16MP11 21.0 CF/CM/CU48C 1200 42.0 27.8 14.50 12.50 40.5 24.2 8.50 3.60 2.68 37.8 27.8
TH4B4221H TM8Y080C16MP11 21.0 CF/CM/CU48D 1200 42.0 27.8 14.50 12.50 40.5 24.4 8.50 3.60 2.68 37.8 28.8
TH4B4221H TM8Y080C16MP11 21.0 CF/CM/CU60C 1200 42.0 27.8 14.75 12.50 40.0 24.2 8.50 3.58 2.66 37.8 28.9
TH4B4221H TM8Y080C16MP11 21.0 CF/CM/CU60D 1225 42.0 28.2 14.75 12.75 40.5 24.2 8.50 3.64 2.68 37.6 29.1
TH4B4221H TM8Y100C16MP11 21.0 CF/CM/CU48C 1200 42.0 27.8 14.50 12.50 40.5 24.2 8.50 3.60 2.68 37.8 27.8
TH4B4221H TM8Y100C16MP11 21.0 CF/CM/CU48D 1200 42.0 27.8 14.50 12.50 40.5 24.4 8.50 3.60 2.68 37.6 27.5
TH4B4221H TM8Y100C16MP11 21.0 CF/CM/CU60C 1200 42.0 27.8 14.75 12.50 40.0 24.2 8.50 3.58 2.66 37.8 28.8
TH4B4221H TM8Y100C16MP11 21.0 CF/CM/CU60D 1225 42.0 28.2 14.75 12.75 40.5 24.2 8.50 3.64 2.68 37.8 28.8
TH4B4221H TM8Y100C20MP11 21.0 CF/CM/CU48C 1275 42.0 28.4 14.50 12.50 40.5 24.4 8.50 3.64 2.70 37.8 28.9
TH4B4221H TM8Y100C20MP11 21.0 CF/CM/CU48D 1275 42.0 28.4 14.75 12.50 40.5 24.4 8.75 3.66 2.70 37.6 29.1
TH4B4221H TM8Y100C20MP11 21.0 CF/CM/CU60C 1275 42.0 28.2 14.75 12.75 40.5 24.4 8.50 3.64 2.68 37.8 27.8
TH4B4221H TM8Y100C20MP11 21.0 CF/CM/CU60D 1275 42.0 28.2 14.75 12.75 40.5 24.2 8.75 3.64 2.68 37.6 27.5
TH4B4221H TM8Y120C20MP11 21.0 CF/CM/CU48C 1275 42.0 28.4 14.50 12.50 40.5 24.4 8.50 3.64 2.70 37.2 28.7
TH4B4221H TM8Y120C20MP11 21.0 CF/CM/CU48D 1275 42.0 28.4 14.75 12.50 40.5 24.4 8.75 3.66 2.70 37.2 28.7
TH4B4221H TM8Y120C20MP11 21.0 CF/CM/CU60C 1275 42.0 28.2 14.75 12.75 40.5 24.4 8.50 3.64 2.68 37.2 28.5
TH4B4221H TM8Y120C20MP11 21.0 CF/CM/CU60D 1275 42.0 28.2 14.75 12.75 40.5 24.2 8.75 3.64 2.68 37.2 28.5
TH4B4221H TM9E080C16MP11 21.0 CF/CM/CU48C 1200 42.0 27.8 14.25 12.25 40.5 24.4 8.50 3.58 2.66 37.8 28.8
TH4B4221H TM9E080C16MP11 21.0 CF/CM/CU48D 1225 42.0 28.4 14.50 12.50 40.5 24.4 8.50 3.62 2.68 37.6 29.2
TH4B4221H TM9E080C16MP11 21.0 CF/CM/CU60D 1200 42.0 27.8 14.50 12.50 40.5 24.2 8.50 3.56 2.64 37.8 28.9
TH4B4221H TM9E100C16MP11 21.0 CF/CM/CU48C 1200 42.0 27.8 14.25 12.25 40.5 24.4 8.50 3.58 2.66 37.8 28.8
TH4B4221H TM9E100C16MP11 21.0 CF/CM/CU48D 1225 42.0 28.4 14.50 12.50 40.5 24.4 8.50 3.62 2.68 37.6 29.2
TH4B4221H TM9E100C16MP11 21.0 CF/CM/CU60D 1200 42.0 27.8 14.50 12.50 40.5 24.2 8.50 3.56 2.64 37.8 28.9
For Notes See Page 29.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces
1
UNIT
MODEL
FURNACE
COIL
MODEL
COOLING HEATING TVA COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
