5005749-CTG-A-0216
Johnson Controls Unitary Products 51
Multipliers for determining the performance with other indoor sections.
TMLX100C16MP11 CF/CM/CU36D 1.03 1.05 0.95
TMLX100C16MP11 CF/CM/CU42C 1.03 1.08 0.95
TMLX100C16MP11 CF/CM/CU42D 1.04 1.08 0.96
TMLX100C20MP11 CF/CM/CU36C 1.02 1.04 0.96
TMLX100C20MP11 CF/CM/CU36D 1.03 1.05 0.94
TMLX100C20MP11 CF/CM/CU42C 1.04 1.08 0.96
TMLX100C20MP11 CF/CM/CU42D 1.04 1.10 0.94
TMLX120C20MP11 CF/CM/CU36C 1.02 1.04 0.96
TMLX120C20MP11 CF/CM/CU36D 1.03 1.05 0.94
TMLX120C20MP11 CF/CM/CU42C 1.04 1.08 0.96
TMLX120C20MP11 CF/CM/CU42D 1.04 1.10 0.94
TP9C060B12MP11 CF42B 1.02 1.05 0.98
TP9C080B12MP11 CF42B 1.02 1.05 0.98
TP9C080C16MP11 CF/CM/CU42C 1.02 1.06 0.98
TP9C100C16MP11 CF/CM/CU42C 1.02 1.06 0.98
TP9C100C20MP11 CF/CM/CU36C 1.02 1.04 0.98
TP9C100C20MP11 CF/CM/CU42C 1.02 1.06 0.98
TP9C120D20MP11 CF/CM/CU42D 1.03 1.08 0.95
TPLC080B12MP11 CF42B 1.02 1.06 0.98
TPLC080C16MP11 CF/CM/CU36C 1.02 1.04 0.96
TPLC080C16MP11 CF/CM/CU42C 1.04 1.10 0.97
TPLC100C16MP11 CF/CM/CU36C 1.02 1.04 0.96
TPLC100C16MP11 CF/CM/CU42C 1.04 1.10 0.97
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. KW
TPLC100C20MP11 CF/CM/CU36C 1.02 1.04 0.98
TPLC100C20MP11 CF/CM/CU42C 1.04 1.10 0.97
TPLC120C20MP11 CF/CM/CU36C 1.02 1.04 0.98
TPLC120C20MP11 CF/CM/CU42C 1.04 1.10 0.97
CP9C060B12MP11 CF42B 1.02 1.05 0.98
CP9C080B12MP11 CF42B 1.02 1.05 0.98
CP9C080C16MP11 CF/CM/CU42C 1.02 1.06 0.98
CP9C100C16MP11 CF/CM/CU42C 1.02 1.06 0.98
CP9C100C20MP11 CF/CM/CU36C 1.02 1.04 0.98
CP9C100C20MP11 CF/CM/CU42C 1.02 1.06 0.98
CP9C120D20MP11 CF/CM/CU42D 1.03 1.08 0.95
CPLC080B12MP11 CF42B 1.02 1.06 0.98
CPLC080C16MP11 CF/CM/CU36C 1.02 1.04 0.96
CPLC080C16MP11 CF/CM/CU42C 1.04 1.10 0.97
CPLC100C16MP11 CF/CM/CU36C 1.02 1.04 0.96
CPLC100C16MP11 CF/CM/CU42C 1.04 1.10 0.97
CPLC100C20MP11 CF/CM/CU36C 1.02 1.04 0.98
CPLC100C20MP11 CF/CM/CU42C 1.04 1.10 0.97
CPLC120C20MP11 CF/CM/CU36C 1.02 1.04 0.98
CPLC120C20MP11 CF/CM/CU42C 1.04 1.10 0.97
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. KW
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO TH4B3521S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
AIR TEMP.
ENTERING
INDOOR COIL (°F)
ID CFM
1000 1200 1400
MBH COP KW MBH COP KW MBH COP KW
60
60 41.0 3.64 2.93 41.6 3.67 2.87 42.2 3.70 2.81
70 39.9 3.24 3.23 40.0 3.25 3.15 40.1 3.27 3.07
80 38.8 2.90 3.54 38.4 2.89 3.44 38.0 2.88 3.33
47
60 35.2 3.22 2.82 35.8 3.25 2.78 36.4 3.27 2.74
70 34.3 2.88 3.12 34.9 2.91 3.07 35.5 2.94 3.01
80 33.5 2.59 3.41 34.0 2.63 3.35 34.6 2.66 3.28
40
60 32.1 2.99 2.77 32.6 3.00 2.74 33.1 3.00 2.71
70 31.4 2.67 3.08 32.0 2.69 3.04 32.6 2.71 3.00
80 30.7 2.39 3.38 31.4 2.43 3.33 32.0 2.46 3.28
30
60 27.4 2.60 2.71 28.1 2.62 2.69 28.7 2.64 2.66
70 26.9 2.33 3.00 27.2 2.33 2.97 27.5 2.33 2.93
80 26.5 2.11 3.30 26.3 2.09 3.25 26.2 2.06 3.20
17
60 23.2 2.30 2.59 23.2 2.22 2.60 23.1 2.15 2.62
70 22.9 2.07 2.86 22.8 2.02 2.87 22.8 1.97 2.87
80 22.5 1.87 3.14 22.5 1.84 3.13 22.6 1.82 3.12
10
60 20.9 1.95 2.77 20.7 1.89 2.75 20.43 1.84 2.73
70 20.6 1.74 3.08 20.6 1.71 3.06 20.5 1.68 3.05
80 20.3 1.58 3.40 20.5 1.56 3.38 20.6 1.55 3.36
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Yellow shaded cells are AHRI High Heating conditions.
Orange shaded cells are AHRI Low Heating conditions.
