Coleman TH4B6021S - Page 52

5005749-CTG-A-0216
52 Johnson Controls Unitary Products
COIL MULTIPLIERS - 3 TON
Air Handler Coil MBH COP KW
AE36BX21 – 0.98 1.07 0.91
AE36CX21 – 0.97 1.09 0.90
AE42CX21 – 0.97 1.12 0.87
AVC36CX21 – 0.97 1.09 0.90
AVC42CX21 – 0.98 1.14 0.86
ME12BN21 CF42B 0.98 1.09 0.90
ME14DN21 CF/CM36D 0.97 1.08 0.89
ME14DN21 CF/CM42D 0.97 1.12 0.87
ME16CN21 CF/CM36C 0.97 1.07 0.90
ME16CN21 CF/CM42C 0.97 1.12 0.86
MVC12BN21 CF42B 0.98 1.10 0.89
MVC14DN21 CF/CM42D 0.97 1.12 0.87
MVC20DN21 CF/CM36D 0.98 1.11 0.88
MVC20DN21 CF/CM42D 0.97 1.10 0.88
FURNACE MULTIPLIERS - 3 TON
Furnaces Coil MBH COP KW
TM8V080B12MP11 CF42B 0.99 1.09 0.91
TM8V080C16MP11 CF/CM/CU36C 0.98 1.08 0.90
TM8V080C16MP11 CF/CM/CU42C 0.98 1.12 0.88
TM8V100C16MP11 CF/CM/CU36C 0.98 1.08 0.90
TM8V100C16MP11 CF/CM/CU42C 0.98 1.12 0.88
TM8V100C20MP11 CF/CM/CU36C 0.98 1.07 0.91
TM8V100C20MP11 CF/CM/CU42C 0.98 1.12 0.88
TM8V120C20MP11 CF/CM/CU36C 0.98 1.07 0.91
TM8V120C20MP11 CF/CM/CU42C 0.98 1.12 0.88
TM8X080B12MP11 CF42B 0.98 1.08 0.91
TM8X080C16MP11 CF/CM/CU36C 0.97 1.06 0.92
TM8X080C16MP11 CF/CM/CU36D 0.97 1.08 0.90
TM8X080C16MP11 CF/CM/CU42C 0.97 1.10 0.88
TM8X080C16MP11 CF/CM/CU42D 0.97 1.12 0.87
TM8X100C16MP11 CF/CM/CU36C 0.97 1.06 0.92
TM8X100C16MP11 CF/CM/CU36D 0.97 1.08 0.90
TM8X100C16MP11 CF/CM/CU42C 0.97 1.10 0.88
TM8X100C16MP11 CF/CM/CU42D 0.97 1.12 0.87
TM8X100C20MP11 CF/CM/CU36C 0.97 1.08 0.90
TM8X100C20MP11 CF/CM/CU36D 0.97 1.09 0.89
TM8X100C20MP11 CF/CM/CU42C 0.97 1.12 0.87
TM8X100C20MP11 CF/CM/CU42D 0.98 1.14 0.86
TM8X120C20MP11 CF/CM/CU36C 0.97 1.08 0.90
TM8X120C20MP11 CF/CM/CU36D 0.97 1.09 0.89
TM8X120C20MP11 CF/CM/CU42C 0.97 1.12 0.87
TM8X120C20MP11 CF/CM/CU42D 0.98 1.14 0.86
TM8Y080B12MP11 CF42B 0.98 1.08 0.91
TM8Y080C16MP11 CF/CM/CU36C 0.97 1.06 0.92
TM8Y080C16MP11 CF/CM/CU36D 0.97 1.08 0.90
TM8Y080C16MP11 CF/CM/CU42C 0.97 1.10 0.88
TM8Y080C16MP11 CF/CM/CU42D 0.97 1.12 0.87
TM8Y100C16MP11 CF/CM/CU36C 0.97 1.06 0.92
TM8Y100C16MP11 CF/CM/CU36D 0.97 1.08 0.90
TM8Y100C16MP11 CF/CM/CU42C 0.97 1.10 0.88
TM8Y100C16MP11 CF/CM/CU42D 0.97 1.12 0.87
TM8Y100C20MP11 CF/CM/CU36C 0.97 1.08 0.90
TM8Y100C20MP11 CF/CM/CU36D 0.97 1.09 0.89
TM8Y100C20MP11 CF/CM/CU42C 0.97 1.12 0.87
TM8Y100C20MP11 CF/CM/CU42D 0.98 1.14 0.86
TM8Y120C20MP11 CF/CM/CU36C 0.97 1.08 0.90
TM8Y120C20MP11 CF/CM/CU36D 0.97 1.09 0.89
TM8Y120C20MP11 CF/CM/CU42C 0.97 1.12 0.87
TM8Y120C20MP11 CF/CM/CU42D 0.98 1.14 0.86
TM9E080C16MP11 CF/CM/CU36C 0.98 1.07 0.91
TM9E080C16MP11 CF/CM/CU36D 0.98 1.08 0.91
TM9E080C16MP11 CF/CM/CU42C 0.98 1.09 0.90
TM9E080C16MP11 CF/CM/CU42D 0.98 1.12 0.88
TM9E100C16MP11 CF/CM/CU36C 0.98 1.07 0.91
TM9E100C16MP11 CF/CM/CU36D 0.98 1.08 0.91
TM9E100C16MP11 CF/CM/CU42C 0.98 1.09 0.90
TM9E100C16MP11 CF/CM/CU42D 0.98 1.12 0.88
TM9E100C20MP11 CF/CM/CU36C 0.97 1.06 0.92
TM9E100C20MP11 CF/CM/CU36D 0.97 1.06 0.92
TM9E100C20MP11 CF/CM/CU42C 0.98 1.10 0.89
TM9E100C20MP11 CF/CM/CU42D 0.97 1.09 0.90
TM9E120D20MP11 CF/CM/CU36D 0.97 1.06 0.92
TM9E120D20MP11 CF/CM/CU42D 0.97 1.09 0.89
TM9V060B12MP11 CF42B 0.98 1.08 0.91
TM9V080B12MP11 CF42B 0.98 1.08 0.91
TM9V080C16MP11 CF/CM/CU42C 0.98 1.09 0.90
TM9V100C16MP11 CF/CM/CU42C 0.98 1.09 0.90
TM9V100C20MP11 CF/CM/CU36C 0.98 1.07 0.92
TM9V100C20MP11 CF/CM/CU42C 0.98 1.08 0.90
TM9V120D20MP11 CF/CM/CU42D 0.97 1.12 0.87
TM9Y080C16MP11 CF/CM/CU36C 0.98 1.07 0.91
TM9Y080C16MP11 CF/CM/CU36D 0.98 1.08 0.91
TM9Y080C16MP11 CF/CM/CU42C 0.98 1.09 0.90
TM9Y080C16MP11 CF/CM/CU42D 0.98 1.12 0.88
TM9Y100C16MP11 CF/CM/CU36C 0.98 1.07 0.91
TM9Y100C16MP11 CF/CM/CU36D 0.98 1.08 0.91
TM9Y100C16MP11 CF/CM/CU42C 0.98 1.09 0.90
TM9Y100C16MP11 CF/CM/CU42D 0.98 1.12 0.88
TM9Y100C20MP11 CF/CM/CU36C 0.97 1.06 0.92
TM9Y100C20MP11 CF/CM/CU36D 0.97 1.06 0.92
TM9Y100C20MP11 CF/CM/CU42C 0.98 1.10 0.89
TM9Y100C20MP11 CF/CM/CU42D 0.97 1.09 0.90
TM9Y120D20MP11 CF/CM/CU36D 0.97 1.06 0.92
TM9Y120D20MP11 CF/CM/CU42D 0.97 1.09 0.89
TMLV080B12MP11 CF42B 0.99 1.09 0.91
TMLV080C16MP11 CF/CM/CU36C 0.98 1.08 0.90
TMLV080C16MP11 CF/CM/CU42C 0.98 1.12 0.88
TMLV100C16MP11 CF/CM/CU36C 0.98 1.08 0.90
TMLV100C16MP11 CF/CM/CU42C 0.98 1.12 0.88
TMLV100C20MP11 CF/CM/CU36C 0.98 1.07 0.91
TMLV100C20MP11 CF/CM/CU42C 0.98 1.12 0.88
TMLV120C20MP11 CF/CM/CU36C 0.98 1.07 0.91
TMLV120C20MP11 CF/CM/CU42C 0.98 1.12 0.88
TMLX080B12MP11 CF42B 0.98 1.08 0.91
TMLX080C16MP11 CF/CM/CU36C 0.97 1.06 0.92
TMLX080C16MP11 CF/CM/CU36D 0.97 1.08 0.90
TMLX080C16MP11 CF/CM/CU42C 0.97 1.10 0.88
TMLX080C16MP11 CF/CM/CU42D 0.97 1.12 0.87
TMLX100C16MP11 CF/CM/CU36C 0.97 1.06 0.92
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil MBH COP KW
