Coleman TH4B6021S - Page 6

5005749-CTG-A-0216
6 Johnson Controls Unitary Products
TH4B3521S AE36BX21 17.5 – 1000 34.4 23.6 14.25 12.00 33.4 21.4 8.50 3.46 2.42 34.2 28.3
TH4B3521S AE36CX21 21.0 – 1230 35.2 26.2 14.50 12.00 34.0 21.6 8.50 3.64 2.48 33.7 28.2
TH4B3521S AE42CX21 21.0 – 1200 35.6 26.8 14.50 12.25 33.8 20.4 8.75 3.74 2.42 34.6 29.3
TH4B3521S AVC36CX21 21.0 – 1125 34.8 25.2 14.25 12.00 33.6 21.6 8.50 3.58 2.46 34.1 28.5
TH4B3521S AVC42CX21 21.0 – 1100 35.4 25.6 14.25 12.25 33.6 18.6 8.75 3.72 2.24 34.8 29.3
TH4B3521S ME12BN21 17.5 CF42B 1150 35.0 25.8 14.00 11.75 34.0 21.6 8.50 3.60 2.44 34.2 28.8
TH4B3521S ME14DN21 24.5 CF/CM36D 1225 35.2 25.6 14.25 12.25 33.6 21.6 8.50 3.62 2.48 34.1 27.7
TH4B3521S ME14DN21 24.5 CF/CM42D 1200 35.4 26.0 14.75 12.25 33.6 21.2 8.75 3.72 2.50 34.4 28.5
TH4B3521S ME16CN21 21.0 CF/CM36C 1225 35.2 25.6 14.25 12.00 33.6 21.6 8.50 3.60 2.48 34.1 27.7
TH4B3521S ME16CN21 21.0 CF/CM42C 1225 35.8 27.0 14.50 12.50 33.6 21.4 8.75 3.76 2.52 34.5 29.3
TH4B3621H AE42CX21 21.0 – 1175 34.2 24.4 15.25 12.50 33.4 19.5 8.50 3.66 2.62 34.5 27.0
TH4B3621H AE48CX21 21.0 – 1175 34.2 24.4 15.25 12.50 33.4 19.5 8.50 3.66 2.62 34.5 27.0
TH4B3621H AE48DX21 24.5 – 1175 34.4 24.4 15.50 12.75 33.4 19.4 8.50 3.68 2.64 34.7 27.0
TH4B3621H AP37CX21 21.0 – 1170 34.0 24.0 14.00 11.75 34.0 20.0 8.20 3.48 2.48 34.1 26.4
TH4B3621H AVC42CX21 21.0 – 1150 34.4 24.2 15.50 12.75 33.4 19.4 8.50 3.66 2.64 34.8 27.1
TH4B3621H AVC48CX21 21.0 – 1150 34.4 24.2 15.50 12.75 33.4 19.4 8.50 3.66 2.64 34.8 27.1
TH4B3621H AVC48DX21 24.5 – 1150 34.6 24.4 16.00 13.00 33.2 19.3 8.50 3.72 2.68 35.0 27.3
TH4B3621H ME14DN21 24.5 CF/CM48D 1175 34.4 24.4 15.50 12.75 33.4 19.4 8.50 3.70 2.64 34.7 27.0
TH4B3621H ME16CN21 21.0 CF/CM48C 1175 34.4 24.4 15.50 12.75 33.4 19.4 8.50 3.68 2.64 34.7 27.0
TH4B4221H AE42CX21 21.0 – 1275 41.5 28.4 14.00 12.00 40.5 24.0 8.50 3.62 2.68 37.6 29.3
TH4B4221H AE48CX21 21.0 – 1225 42.0 28.0 14.75 12.50 40.0 24.2 8.75 3.64 2.70 37.6 28.7
TH4B4221H AE48DX21 24.5 – 1225 42.0 28.0 15.00 12.75 40.0 24.0 9.00 3.66 2.72 37.6 28.7
TH4B4221H AE60CX21 21.0 – 1275 42.0 27.8 14.25 12.25 41.0 24.6 8.50 3.56 2.62 37.2 28.0
TH4B4221H AVC42CX21 21.0 – 1250 42.0 27.8 14.50 12.25 40.5 24.4 8.50 3.60 2.68 37.4 28.3
TH4B4221H AVC48CX21 21.0 – 1275 42.0 28.4 14.50 12.50 40.5 24.4 8.50 3.64 2.68 37.2 28.7
TH4B4221H AVC48DX21 24.5 – 1300 42.0 28.6 14.75 12.75 40.5 24.2 9.00 3.68 2.72 37.0 28.6
TH4B4221H AVC60CX21 21.0 – 1275 42.0 27.8 15.00 13.00 40.5 24.2 9.00 3.68 2.70 37.2 28.1
TH4B4221H ME14DN21 24.5 CF/CM48D 1175 42.0 27.8 14.75 12.75 40.0 24.0 8.75 3.64 2.72 38.1 29.1
TH4B4221H ME14DN21 24.5 CF/CM60D 1225 42.0 28.0 15.00 13.00 40.0 24.0 9.00 3.70 2.74 37.6 28.7
TH4B4221H ME16CN21 21.0 CF/CM48C 1225 42.0 28.6 15.00 12.75 40.5 24.2 9.00 3.70 2.74 37.6 29.4
TH4B4221H ME16CN21 21.0 CF/CM60C 1225 42.0 28.0 15.00 13.00 40.0 24.2 9.00 3.68 2.72 37.6 28.7
TH4B4221H ME20DN21 24.5 CF/CM48D 1425 42.0 29.8 14.75 12.50 41.0 24.6 8.75 3.72 2.70 35.9 28.4
TH4B4221H ME20DN21 24.5 CF/CM60D 1450 42.0 29.6 15.00 12.75 41.0 24.6 8.75 3.72 2.70 35.7 28.1
TH4B4821S AE48CX21 21.0 – 1,400 46.0 31.8 14.25 12.00 47.5 31.4 9.00 3.58 2.64 41.5 33.4
TH4B4821S AE48DX21 24.5 – 1,400 46.5 32.0 14.50 12.25 47.5 31.4 9.00 3.62 2.66 42.0 33.7
TH4B4821S AE60CX21 21.0 – 1,520 47.0 33.3 15.00 12.50 47.5 31.4 9.00 3.66 2.66 42.4 34.1
For Notes See Page 7.
SYSTEM CAPACITY - Single Piece and Modular Air Handlers
UNIT
MODEL
AIR HANDLER
COIL
MODEL
3
RATED
CFM
COOLING
1
HEATING
2
TVA COOLING
MODEL WIDTH
NET MBH
SEER EER
NET MBH
HSPF
COP NET MBH
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD TOTAL SENS.
