1.4 17 DIGIT VIN MATRIX
Digit 1 – 3 Mfg. ID
5FC = Columbia ParCar
Digit 4 Vehicle Type
L = Low Speed Vehicle
Digit 5 Series
S = Summit
Digit 6 Body Type
2 = Two Person
3 = Long Bed
4 = Four person
5 = Short Bed
Digit 7 Engine Type
6 = 48 Volt DC Drive
8 = 48 Volt AC Induction Drive
Digit 8 Restraint
A = Type 1 Seat Belt Assembly
B = Type 2 Seat Belt Assembly (3 point)
Digit 9
Assigned Check Digit
Digit 10 Model Year
B = 2011, C = 2012, D = 2013 etc.
Digit 11 Plant Location
1 = Reedsburg
Digit 12 - 17
123456 = Build Sequence
To ensure prompt service when repairs or adjustments are required, your Columbia Dealer must have the VIN.
An example of a current 13 digit VIN is SUSEB-4YL1234
An example of a current 17 digit VIN is 5FCLS36A681123456.
For your own personal reference, fill in the VIN in the space provided below:
1.5 VEHICLE SPECIFICATIONS
SM-2 SM4 SUV-S SUV-L
Max. Speed
19 mph non-NEV
25 mph NEV
Max. Range* Up to 40 miles Up to 35 miles Up to 40 miles Up to 35 miles
Passenger 2 4 2 2
Power 48 Volt DC Drive Standard, 48 Volt AC Drive Optional
Brakes Hydraulic rear drums, Hand parking brake
Overall
L x W x H (Inches)
99 x 48 x 72 124 x 48 x 72 107 x 48 x 72 131 x 48 x 72
Wheelbase 66 92 76 91
Ground Clearance (Inches) 5.5
Flat Bed (inches) - - 36 x44 60 x 44
Curb Weight (lbs) 1500 1780 1600 1750
Gross Vehicle Weight (lbs) 2090 2550 2338 2735
Lighting – Non-NEV do not
have all listed
Headlights, Taillights, Brake Lights, Back-up Lights,
Emergency Flashers, Reflectors, License Plate, Turn Signals
Windshield/Mirrors Safety Glass Windshield, Rear & Side Mirrors
Charger Built-in, micro-processor controlled with remote LED
Battery Eight, 6 volt
1-3
2012 Summit
