IGS-NT Installation Guide

6.1.8.5. Connection to IS-NT-BB

RS232(1)

RS485(1)

CAN1

Extension

CAN2

Intercontroller

Terminal 1*:

InteliVision 8

Channel 1

InteliVision 8

Channel 2

InteliVision 8

Channel 3

InteliVision 8

Channel 4

InteliVision 8

Communication:

InteliVision 8

RS232(2)

Communication:

InteliVision 8

RS485(2)

Communication:

InteliVision 8

HINT

*Up to three displays could be connected with IS-NTC-BB via RS 485(1) – Display.

Communication on RS232(2) can be switched to RS485(2) so one InteliVision can be

connected to these two ports only.
