„2“- e.g. 0.36 MPa
„3“ - e.g. 0.366 MPa
Set to: 1
When Analog input configuration is finished set the setpoints Wrn Oil press, Sd Oil press, Oil press del
in Engine protection group.
Each Analog input has separate triplet of setpoints: Wrn level, Sd level, Anl Inp del. Names of these
setpoints are fix defined
Number of decimal points of Wrn level1 and Sd level is the same as the configured number of
decimal points of measured value.
Binary inputs
Binary outputs
+
Battery
-
iL
4k7
Ω
+
-
Power
Supply
+
Battery
-
iL
LOAD
+
-
Power
Supply
InteliLite – MRS10/11/15/16, SW version 2.2, ©ComAp – November 2004 18
IL-MRS-2.2.pdf
