Curr unbal [%]
Threshold for generator current asymmetric (unbalance).
Step: 1% of Nominal current
Range: 1 – 200% of Nominal current
Curr unbal del [s]
Delay for generator current assymetry
Step: 0.1 s
Range: 0 – 60.0 s
Gen >V Sd [%]
Shutdown level for generator overvoltage. All three phases are checked. Maximum out of three is
used.
Step: 1% of Nominal voltage
Range: Gen <V – 200%
Gen <V Sd [%]
Shutdown level for generator undervoltage. All three phases are checked. Minimum out of three is
used.
Step: 1% of Nominal voltage
Range: 0% – Gen >V
Gen V del [s]
Delay for generator undervoltage and overvoltage alarm
Step: 0.1s
Range: 0 – 60 s
Volt unbal [%]
Threshold for generator voltage unbalance alarm.
Step: 1% of Nominal voltage
Range: 0 – 100% of Nominal voltage
Volt unbal del [s]
Delay for generator voltage unbalance alarm.
Step: 0.1s
Range: 0 – 60.0 s
Gen >f [%]
Shutdown level for generator overfrequency.
Step: 0.1% of Nominal frequency
Range: Gen <f – 200.0%
Gen <f [%]
Shutdown level for generator underfrequency.
Step: 0.1% of Nominal frequency
Range: 0.0 – Gen >f
Gen f del [s]
Delay for generator underfrequency and overfrequency alarm.
Step: 0.1s
Range: 0 – 60.0 s
InteliLite – MRS10/11/15/16, SW version 2.2, ©ComAp – November 2004 35
