Generator Gen curr L3 0 A 8200 Unsigned 16
Binary I/O BInpIL 001000 8235 Binary 16
Binary I/O BOutIL 000001 8239 Binary 16
Statistics kWhours 0 8205 Integer 32
Statistics kVArhours 0 8539 Integer 32
Statistics NumStarts 0 8207 Unsigned 16
Statistics RunHours 0 h 8206 Integer 32
Statistics NextServTime 65534 h 9648 Unsigned 16
IL info TimerText Ready 8954 Unsigned 16
IL info TimerValue 0 s 8955 Unsigned 16
IL info SW version 2,1 8393 Unsigned 8
IL info SW branch 1 8707 Unsigned 8
IL info Application 4 8480 Unsigned 8
IL info ControllerMode 0 9651 Unsigned 8
IL info DiagData 0 10050 Unsigned 32
IL info PasswordDecode 2481875985 9090 Unsigned 32
RA15 module BOutRA15 000000000000000 9849 Binary 16
IOM/PTM module AnInIOM 1 0 U4 8978 Integer 16
IOM/PTM module AnInIOM 2 0 U5 8759 Integer 16
IOM/PTM module AnInIOM 3 0 U6 8760 Integer 16
IOM/PTM module AnInIOM 4 0 U7 8761 Integer 16
IOM/PTM module BInpIOM 00000000 8602 Binary 16
IOM/PTM module BOutIOM 00000000 8604 Binary 16
ECU Fuel rate ##### L/h 9860 Unsigned 16
ECU Water temp ##### °C 9855 Integer 16
ECU ManifoldTemp ##### °C 9878 Integer 16
ECU Oil press ##### Bar 9929 Unsigned 16
ECU Boost pressure 0,0 Bar 9877 Unsigned 8
ECU PercLoadAtCS 0 % 9925 Unsigned 8
1
In case of software malfunction DiagData shows the value that enables to locate possible bug in
software. Include this number when reporting a software problem.
InteliLite – MRS10/11/15/16, SW version 2.2, ©ComAp – November 2004 61
