ComAp NPU User Manual

NPU, SW Version 1.8, ©ComAp, September 2003
NPU-1.8r2.PDF 16
Default setting
No. Quantity (parameter) Rated voltage
100V 230V 400V 480V
A1 Frequency in L1, L2, L3
A2 Voltage L1
A3 Voltage L2
A4 Voltage L3
A5 Max. phase asymmetry
A6 Max. vector shift in L1, L2, L3
A7
A8
Overfrequency limit
Overfrequency delay
52 (62) Hz
2,5 s
52 (62)Hz
2,5 s
52 (62) Hz
2,5 s
52 (62) Hz
2,5 s
A9
A10
Underfrequency limit
Underfrequency delay
48 (58) Hz
2,5 s
48 (58) Hz
2,5 s
48 (58) Hz
2,5 s
48 (58) Hz
2,5 s
A11
A12
A13
A14
Overvoltage limit L1
Overvoltage limit L2
Overvoltage limit L3
Overvoltage delay
110 V
110 V
110 V
2,5 s
253 V
253 V
253 V
2,5 s
440 V
440 V
440 V
2,5 s
528 V
528 V
528 V
2,5 s
A15
A16
A17
A18
Undervoltage limit L1
Undervoltage limit L2
Undervoltage limit L3
Undervoltage delay
85 V
85 V
85 V
2,5 s
196 V
196 V
196 V
2,5 s
340 V
340 V
340 V
2,5 s
432 V
432 V
432 V
2,5 s
A19
A20
Voltage asymmetry limit
Asymmetry delay
15 V
2,5 s
30 V
2,5 s
60 V
2,5 s
60 V
2,5 s
A21
A22
Vector shift limit
Vector shift evaluation delay on
voltage connection
20
2,5 s
20
2,5 s
20
2,5 s
20
2,5 s
