Optical Unit Management Screen
Figure 43: MU Device - Optical Unit
Note: MU transmit optical power is -4~-2dBm.
RF Unit Management Screen
Figure 44: MU Device - RF Unit
FOU port number
Optical loss between MU
and RU, the value is over
16dB when MU and RU are
not connected well
Optical power alarm. Alarm is
triggered when optical power is
less than -10dBm. Indicator will
turn from green to red.
Click here to enable/disable
optical RX/TX alarm
Slot number
Band and Remark
information
RF parameter
Commissioning
status
To Next Page
