TableofContents
Simoom®Technology…………………………………………… 3
Set‐UpProcedures……………………………………………… 4‐5
TankOrifice&BypassTube……………………………………6
PowderGate®Valve……………………………………………… 7
Tune‐upKits…………………………………………………………… 7
AF10‐EComponents……………………………………………… 8
MaintenanceCounters..………………………………………… 9
Modulator……………………………………………………… 9
Troubleshooting……………………………………………… 10
ElectricalSchematic………………………………………… 11
PneumaticSchematic……………………………………… 12
WarrantyInformation………………………………………13
AccuFlo® Nozzles…………………………………………… 14
FixturingGuide………………………………………………..14
AccuFlo®AF10‐ESpecifications
Model AccuFlo® AF10‐EStandardTank AccuFlo®AF10‐ETTallTank
ShippingWeight 30lb.(13.6kg) 30lb.(13.6kg)
Height 10.5in.(26.7cm) 15.0in.(38.1cm)
Width 17.5in(44.5cm) 17.5in.(44.5cm)
Depth 10.0in.(25.4cm) 10.0in.(25.4cm)
AirPressure 10– 125psi(0.7– 8.6bar) 10– 125psi(0.7– 8.6bar)
Powder Capacity 1liter 2liters
NozzleSizes Round.015‐.060in.Ø(.38mm– 1.5mm)Othershapes&sizesavailable.
FacilityRequirements
InletAirPressure 70– 145psi(4.8– 10bar)
Air Volume Dependingonnozzlesizeandairpressure,consumption istypically
0.2– 4.6SCFM(94– 2170cm
3
/sec)
AirSupplyQuality Driedto‐25° Fdewpoint(200 ppmofmoisture)andoilcontentfilteredto
<10ppm
Power Requirements 115V60Hz,40W
230V 50Hz,40W
2
