PowderGate®Valve
ThePowderGate®NoseandOutputFittingshouldbereplacedafter250,000cycles.Theyarebothincluded
intheTune‐UpKit.
• UnscrewtheOutputFittingwitha¾"wrench.
• Withpliers,gentlypullthewornNosefromshaft.
• PressonnewNose.
• InstallthenewOutputFitting.
• ConnectthetubingwiththeblueQuicknut.
Tune‐UpKits
ABRASIVEHOSE
MB1233
POWDERGATEOUTPUTFITTING
MB2560‐x
POWDERGATENOSE
MB1653
TUNE‐UPKITMB2247‐x
MB2247‐2
1/4"output fitting
MB2247‐3
3/8"output fitting
PowderGate
OutputFitting
MB2560‐3 MB2560‐4
PowderGate
Nose
MB1653
O‐ring ST5650‐242
Inadditiontothetune‐upkit,wealsorecommendthatyoukeepaback‐upsupplyofnozzlesandorificesto
fityourapplication.
