Comelit IPCAM720A - Connecting the Power

Connecting the Power
Connect the DC 12V power adaptor to the camera.
No Name Description
1 Power Cable
Cable for Power source (DC 12V)
2 Ethernet Cable
Cable for Ethernet (POE)
[IPCAM720A] [IPCAM722A]
[IPCAM727A][IPCAM702A]
[IPCAM700A]
1
2
1 2 1 2
1
2
1 2
